Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery
Specifications
Brand Name :
GME
Certification :
CE
Place of Origin :
China
MOQ :
50pcs
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
100000 pcs per Month
Delivery Time :
7~10 working days
Packaging Details :
cartons， pallet
Power Source :
Electric
Dimension :
Customized
Voltage :
12-480V
Sheath material :
Stainless Steel or Nickel
Style :
K, J
Lead wire :
copper, , fiberglass silicon
Insulation Material :
MgO
Heating Element :
Nichrome Resistance
Screw Threads :
Available
Flange Washer :
Available
Tube Diameter :
2mm - 30mm
Description

Resistance tube Rod heater Cartridge Heating Element For Packing Machinery


Description:

* Tubular heating element are custom designed in a various shapes to as client's requirements for direct immersion in liquids such as water, oils, solvents and process solutions, molten materials as well as air and gases.

* Tubular heaters are produced using Incoloy, stainless steel or Copper sheath materials and also there is huge variety of selection of termination styles available. Insulation of Magnesium offers greater heat transfer.
* Tubular heaters can be used in any application. Straight tubular can be inserted in machined groves for conductive heat transfer and formed Tubular provides consistent heat in any type of special application.your specifications.


Specification:

(1.) Tube diameter: Φ3mm-Φ30mm

(2.) Tube Material:SS304;SS316,SS321,NICOLOY800 etc

(3.) Insulation Material:High-purity Mgo

(4.) Reisistance wire element:Ni-Cr or FeCr

(5.) Lead Connection Option: Crimped or Swaged leads

(6.) Lead and type of connection leads, 10" Fiberglass Standard(Wire options:,silicone high temperature frberglass)

Heat intensity Not exceeding 30Wcm2 (advisable)
Power Depends on the dimension
Escape of current (when cold) <=0.1mA a 242 v.
Insulation (when cold) 5 Min Ohmios 500 Watts minimum
Dielectric strength 1500v. 1/seg
Working temperature 750ºG max.
Tolerance of length +/-1.5%
Tolerance of diameter -0.01 a -0.06 m/m
Tolerance of cut of connexion +/-15 mlm
Power tolerance (w) 5 % - 10 %
Cold areas Depends on length and diameter 5-25mm

Nichrome Resistance Dia 30mm Cartridge Heating Element For Packing Machinery


Application:

l Plastic Processing machinery.

l Water and Oil Heating Appliances.

l Packaging machineries

l Vending Machines.

l Dies and Tools.

l Heating Chemical Solutions.

l Ovens & Dryers

l Kitchen equipments

l Medical equipments
