Resin Texture Pure Epoxy Powder Coating RAL 2009 Orange Color
Resin Texture Pure Epoxy Powder Coating RAL 2009 Orange Color
Resin Texture Pure Epoxy Powder Coating RAL 2009 Orange Color
Resin Texture Pure Epoxy Powder Coating RAL 2009 Orange Color
Specifications
Brand Name :
TOPO
Model Number :
RAL2009
Certification :
CE, BV, ROHS
Place of Origin :
Ukraine
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
400 T/Month
Delivery Time :
7 days
Packaging Details :
Two-ply PVC bag inside with carton box, net weight 20/25kg
Color :
ORANGE
Surface Type :
metal
Package :
20kg
Main material :
Resin
Surface :
No cracking powder
Application :
home appliance
Description

Pure Epoxy Powder Coating texture RAL 2009 Orange Color Powder Coating

Curing temperature

Standard type: 180oC/15 minutes

Or 160oC/20 minutes, 200oC/10 minutes if customer require

Chemical resistance to most solvents and mild acids and bases is good, and epoxy powder coatings provide excellent toughness and corrosion resistance.


Adhesion to metal substrates is excellent, and generally epoxy powder coatings do not require a primer.

Product Details
Type Epoxy Powder Coating
Gloss Level Semi Gloss 90%
Surface Finish Smooth

Powder Property
Appearance Fine powder
Particle Size Average 32-40μm
Specific Gravity 1.3-1.5g/cm3
Coverage 7-8 square meter per Kg at 80μm film thickness
Application Recommendation
Applicatoin Corona
Application Voltage 60-90 KV
Gun to Component Distance 15-30 CM
Film Thickness 80-90μm
Curing Temperature 190℃(Object temperature) for 15 minutes
Powder Coated Film Mechanical Properties
Adhesion Cross-cut (2mm), no loss of adhesion
Impact Resistance Direct & Indirect 50kg/cm
Pencil Hardness 2H
Flexibility 7mm Mandrel
Bending Test 3mm

Resin Texture Pure Epoxy Powder Coating RAL 2009 Orange Color
