1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
Specifications
Brand Name :
PM
Model Number :
M6-M18, 1/4"-1"
Certification :
ISO
Place of Origin :
CHINA
MOQ :
100PCS
Price :
USD 0.001-0.86 PER PCS
Payment Terms :
L/C, T/T
Supply Ability :
100 Tons per Month
Delivery Time :
15-25DAYS PER CONTAINER
Packaging Details :
25kgs/carton and 36 cartons on standard export wooden pallets
Material :
C1010,C10222
Grade :
4.8, 2
Size :
1/2"
Length :
70-305mm
Surface :
Zinc Plated ( Clear/Blue/Yellow/Black )
Thread :
UNC
Mark :
Manufacturer's ID and Diameter
Product name :
1/2 inch thread UNC Concrete Wedge Anchor expansion Bolts
Description

1/2 inch thread UNC Concrete Wedge Anchor expansion Bolts

Wedge anchors are designed to anchor objects into concrete. They are installed into a pre-drilled hole, then the wedge is expanded by tightening the nut to securely anchor into the concrete. They are not removable after the anchor is expanded.

SIZE: 1/4" - 1", M6 -M18.

STANDARD: ASME B18.2.6

THREAD: ASME B1.1 , UNC, UNF, CLASS 2A

FINISHED: Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, Nickel, Dacromet, H.D.G.

Thread Drill hole Length range Thread Drill hole Length range
(mm) (mm) (mm)
M6 6 40-120 1/4" 1/4" ≈45-120
M8 8 50-220 5/16" 5/16" ≈50-145
M10 10 60-250 3/8" 3/8" ≈60-200
M12 12 70-400 1/2" 1/2" ≈70-305
M14 14 80-200 5/8" 5/8" ≈80-305
M16 16 80-300 3/4" 3/4" ≈90-305
M18 18 100-300 1" 1" ≈125-405
M18 20 100-400
M18 24 120-400

1/2 Inch Thread UNC Concrete C1010 Metric Wedge Type Anchor
