Class 4.8 Carbon Steel Q235 One Side Thread Galvanized J Hook Anchor Bolts
Class 4.8 Carbon Steel Q235 One Side Thread Galvanized J Hook Anchor Bolts
Class 4.8 Carbon Steel Q235 One Side Thread Galvanized J Hook Anchor Bolts
Class 4.8 Carbon Steel Q235 One Side Thread Galvanized J Hook Anchor Bolts
Specifications
Brand Name :
PM
Model Number :
M6-M64, 1/4"-4"
Certification :
ISO
Place of Origin :
CHINA
MOQ :
100PCS
Price :
USD 0.001-3 PER PCS
Payment Terms :
L/C, T/T
Supply Ability :
1000 Tons per Month
Delivery Time :
15-25DAYS PER CONTAINER
Packaging Details :
25kgs/carton and 36 cartons on standard export wooden pallets
Material :
Q235
Diameter :
3/4"
Length :
1000mm
Grade :
4.8
Thread :
UNC,
Sample :
All sample free
Surface :
Galvanized
Product :
Class 4.8 carbon steel Q235 steel one side thread galvanized anchor j bolts
Description

Class 4.8 carbon steel Q235 steel one side thread galvanized anchor j bolts

Hot-dipped galvanized (wedge) anchor bolts are designed for use in solid concrete. They should never be installed into soft, hollow base materials. The hot-dipped galvanized coating is excellent for use in moist atmospheres where more rust resistance is required than the standard zinc plated wedge anchors can provide.

Anchor bolts are commonly used in the construction and engineering industries to attach objects or structures to concrete. L-Shaped Anchor Bolts (masonry anchors) vary in shape, size and material, depending on the specific application, however they all consist of a threaded end where a nut and washer can be attached for the external load.

Type :
Full threads, Partial Threads, and customized as per requirements.

SIZE :
Nom Dia: ¼ to 4″ [6-100 mm]

Length: As Per Standard or Upto any Length

SPECIFICATION / STANDARD :ASTM / ASME / BS / DIN / BS EN ISO

MATERIAL :C.S., M.S., Alloy Steel, Ferritic & Austenitic Stainless Steel


THREADS :UNC, 8UN, UNF, Metric Coarse & Fine Series.


SURFACE FINISH :Self Color, Hot Dip Galvanized, Electro Galvanized, Di-Chromated, P.T.F.E. Coated or any other as per order requirement

Class 4.8 Carbon Steel Q235 One Side Thread Galvanized J Hook Anchor Bolts

J429 MECHANICAL PROPERTIES
Grade Size Full Size Proofload, psi Yield Strength, psi min. Tensile Strength, psi min. Elong. min. RA min. Core Hardness, Rockwell Tempering Temperature
2 1/4" - 3/4" 55,000 57,000 74,000 18 35 B80 to B100 NA
over 3/4" - 1-1/2" 33,000 36,000 60,000 18 35 B70 to B100
5 1/4" - 1" 85,000 92,000 120,000 14 35 C25 to C34 800F
over 1" - 1-1/2" 74,000 81,000 105,000 14 35 C19 to C30
8 1/4" - 1-1/2" 120,000 130,000 150,000 12 35 C33 to C39 800F

Packaging Details: a. bulk in cartons (<=25kg )+ 36CTN/wood solid Pallet

b. bulk in cartons 9"x9"x5" (<=18kg )+ 48CTN/wood solid Pallet

Supply Ability:1000 tons per month

MinimumOrder:200kgs for each specification

Trade Term:FOB/CIF/CFR/CNF/EXW/DDU/DDP

Payment :T/T, L/C , D/A , D/P , Western Union,etc

Market:South&north Amrica/Europe/ etc.
