2 Sided Automated Pcb Assembly Manufacturing Flexible Printed Circuit Assembly Ai Pcb Layout
2 Sided Automated Pcb Assembly Manufacturing Flexible Printed Circuit Assembly Ai Pcb Layout
Specifications
Brand Name :
kerongda
Model Number :
KRD-AIPCB06
Certification :
CE
Place of Origin :
Qingdao China
MOQ :
1k
Price :
USD0.01~0.1/dot
Supply Ability :
40000dot/h
Delivery Time :
15 days
Packaging Details :
Standard packet
Turnkey PCBA :
PCB+components sourcing+assembly+package
Lead Time :
Prototype: 15 work days. Mass order: 20~25 work days
Testing on products :
Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity :
Min quantity: 1000pcs. Prototype, small order, mass order, all OK
Files we need :
Assembly: Pick-N-Place file
PCB panel Size :
Min size: 0.25*0.25 inches(6*6mm)，Max size: 20*20 inches(500*500mm)
Copper thickness :
1oz,0.5-2.0 oz,1-3oz,0.5-5oz,0.5-4oz
Base material :
FR4, Aluminium, TG, Rogers, CEM-1
Description

Ai Pcba/Pcba/Oem/Control Board/Smt/Pcb Assembly/Oem Pcba/Fr-4

DIP

1,The process of DIP processing is: putting in the hole →AOI→ wave soldering → cutting pin →AOI→ correction → washing → quality inspection.

2,After wave soldering, The products will be will scanned by AOI equipment to ensure that no error occurs.

Single-side mixed loading process

Incoming material detection => PCB side A screen printing solder paste (spot patch glue) => patch => drying (curing) => reflow welding => cleaning => plug-in => wave soldering => cleaning => detection => repair

Double-sided mixed loading process

A: Incoming material detection =>PCB B spot patch glue => patch => curing => turn over =>PCB A side plug-in => wave soldering => cleaning => detection => repair

Stick before insert, suitable for SMD components more than separate components

B: Incoming material detection => PCB side A plug-in (pin bent) => turn over => PCB side B patch glue => patch => curing => turn over => wave soldering => cleaning => detection => repair

Insert before paste, suitable for separated components more than SMD components

No. Types Of Assembly File Format Component Footprinr Component Package Testing Produres Produres Others
1 SMT ASSEMBLY Gerber RS-274X 0201,0402,0603... Reels Package Visual Inspection Lead-Free(Rohs) Custom Reflow Profile
2 SMT & THT Assembly BOM(.xls,.csv,.xlsx) BGA,QFN,QFP,PLCC Cut Tape Package X-Ray Inspection Leaded Solder Standard Reflow Profile
3 2 sided SMT,THT Assembly Pick-N-Place/XY file SOIC,POP...Connectors Tube and Tray AOI,ICT(In-Circuit Test) Reflow Soldering Smallest Size:0.2"x0.2"
4 Mixed Assembly ... Small Pitch of 8 Mils Loose parts and bulk Functional Testing Wave Soldering Largest Size:15"x"20

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Files we need Components: Bill of Materials(BOM list)
Files we need Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
Components details BGA and VFBGA
Components details Leadless Chip Carriers/CSP
Components details Double-sided SMT Assembly
Components details Fine Pitch to 0.8mils
Components details BGA Repair and Reball
Components details Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCB assembly Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing


Our Advantages:

1. Program and functional test and package by Free.

2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.

3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.

4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949

Q&A

Q: What files do you use in PCBA fabrication?

A: Gerber or Eagle, BOM listing, PNP and Components Position.

Q: Is it possible you could offer sample?

A: Yes, we can custom samples for your testing before mass production.

Q: How much time could I get the quotation after sent Gerber, BOM and test procedure?

A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.

Q: How can I know the process of my PCBA production?

A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing.

Q.What is the warranty?

The warranty is 2years.
