Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
Specifications
Brand Name :
HC
Model Number :
HC17
Certification :
ISO
Place of Origin :
Botou Hebei China
MOQ :
1Set
Price :
8000-12000USD
Payment Terms :
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Supply Ability :
20 Sets/Month
Delivery Time :
30days
Packaging Details :
Main machine is nude,the computer control box is packed by carton box.
Roller Material :
Cr12 Steel Quenched
Cutting Blade Material :
Cr 12Mov
Shaft Material :
High Grade 45#Steel
Voltage :
380V 50Hz 3Phases
Warranty :
1 Year
Condition :
New
Description

Steel Silo Corrugated Roll Forming Machine For Roof Sheet

General Introduction
This metal roll forming machine is corrugating color coated iron high rib roofing and wall cladding sheets with a high speed and perfect quality. The raw materials can be galvalume steel coils, galvanized steel coils or aluminium coils. The applications

● Factory sheds

● Railway stations

● Ware houses

● Metro Stations

● Aircraft hangers

● Power Plants

● Work Shops

● Petrol Pump Canopies

● Super Markets

● Pre Fabricated structures

● Other miscellaneous structures

Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet

Technical Specifications of Color Coated Steel Hi Rib Roofing Sheet Roll Forming Machine

Technical Items Details
Raw Material Type Aluminium & Steel Coils, PPGI, GI, PPGL
Width 1200 mm, 1220mm
Thickness 0.3-0.7 mm
Yield Strength 235-345 MPa or specially designed for 550 MPa
Finished Products Cover width 1000 mm
Length Adjustable
Required Power Voltage 220V/380V/415V/440V
Driving Motor 7.5 KW
Cutting Motor 2.2 KW
Production Speed 900-1200 meters per hour
Coil Decoiler Type Un-powered or Powered
Capacity 5 tons
Rolling Stations of Roll Former 12 sets
Rolling Shaft Diameter 72 mm
Cutting Type Post-cutting
Operation System Mitsubishi PLC, transducer and touching screen
Supporting Tables 2 sets
Machine Size Around 6.2 x 1.6 x 1.5 meters
Machine Weight Around 3.2 tons

Main Components Color Coated Steel Hi Rib Roofing Sheet Roll Forming Machine

No. Items List Quantity
1 Coil Decoiler 1 set
2 Main Machine Direction Guilder 1 set
Roll Former System 1 set
Post-cutting Device 1 set
3 Supporting Tables for Finished Products 2 sets
4 Hydraulic Station for Cutter 1 set
5 Auto PLC Control Cabinet 1 set
6 Tooling Box with Spare Parts 1 set

More Roofing Sheets Profiling Machine Pictures for Reference

Steel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof SheetSteel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof SheetSteel Silo PPGI Corrugated Roll Forming Machine For 0.7mm Roof Sheet
