High Speed Metal C Purlin Roll Forming Machine For Building Steel Structure
High Speed Metal C Purlin Roll Forming Machine For Building Steel Structure
Specifications
Brand Name :
HC
Model Number :
HC80-300
Certification :
ISO
Place of Origin :
Botou Hebei China
MOQ :
1set
Payment Terms :
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability :
20 sets/month
Delivery Time :
30days
Packaging Details :
Main machine is nude,the computer control box is packed by carton box
Suitable material :
Galvainzed steel
Usage :
Roof purlin
Capacity :
8-10m/min
Punching :
Yes
Thickness :
3mm
Worker :
1 only
Power :
11+7.5KW
Warranty :
Whole life
Description

High Speed Metal C Purlin Roll Forming Machine for Building Steel Structure

Building Steel Structure Metal C Purlin Roll Forming Machine With High Speed is the special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, decoiling, continuous rolling and cold-forming, automatically cut to the size and specification which is required, and output the finished panels. The equipment adopts PLC control, AC frequency and adjusting the speed technology, and it realizes the continuous automatically production, therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.

Technical Parameters

No Item Parameter Remark
1

Suitable

Material

 Type Galvanized steel
Width(mm) According to customer's requirement
Thickness(mm) 1.2-2.4 According to customer's requirement
Yield Strength(Mpa) 550 According to customer's requirement
2 Forming Speed(m/min) 20 Not including cutting time
3 Material of Punching Die bearing steel with quench treatment
4 Cutting Model hydraulic cutting According to customer's requirement
5 Power source Type 440V/3PH/60HZ According to customer's requirement

Machine Components

No Name Quantity Remarks
1 Decoiler 1set Up to customer
2 Main machine Pre-cutting device 1set Up to customer
Feeding device 1set
Roll forming system 1set
Post cutting device 1set
Hydraulic system 1set
3 Electric control system 1set
4 Supporter/Automatic Stacker 1set

Up to customer

Profile Drawing

High Speed Metal C Purlin Roll Forming Machine For Building Steel Structure

High Speed Metal C Purlin Roll Forming Machine For Building Steel Structure

Working Flow
Decoiler --- Fedding & Leveling --- Roll Forming --- Punching --- Cut-to-length --- Run out table

Main Components

  • Decoiler ---------------------------------------------- 1 Unit
  • Feeding & Leveling -------------------------------- 1 Unit
  • Main roll forming machine ------------------------ 1 Unit
  • Hydraulic punching device ----------------------- 1 Unit
  • Hydraulic cutting device -------------------------- 1 Unit
  • Hydraulic Station ----------------------------------- 1 Unit
  • PLC computer control ----------------------------- 1 Unit
  • Output table ----------------------------------------- 1 Unit

Application

C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure

Our Advantage

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

High Speed Metal C Purlin Roll Forming Machine For Building Steel StructureHigh Speed Metal C Purlin Roll Forming Machine For Building Steel Structure
