Double Layer PPGI / GI Glazed Sheet Roll Forming Machine
Double Layer PPGI / GI Glazed Sheet Roll Forming Machine
Specifications
Brand Name :
HC
Model Number :
HC25-104-1020-1250
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
20set per month
Delivery Time :
20-30 work days
Packaging Details :
Main machine is nude，The workbench is packed with plastic stretch film
Material Type :
PPGI/GI
Material Thickness :
0.3-0.6mm
Material Width :
1250mm
Roller Stations :
12 Stations
Roller & Shaft Material :
45# Steel Quenching and Plating
Diameter of Shaft :
Φ70mm
Cutter Material :
CR12
Drive Type :
Chain Drive
Speed :
4m/min
Total Power :
5.5+5.5KW
Voltage :
380v 50Hz 3phases
Description

Product Description

With humanized design and advanced control system, the operation interface is simple and intuitive, and operators can master the operation skills after simple training. The equipment has a high degree of automation, and many production parameters can be quickly set and adjusted through the control system, reducing the complexity and difficulty of manual operation.

Main Technical Parameters

Material Type PPGI/GI
Thickness 0.3-0.6mm
Width 1250mm
Roller Stations 12Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ70mm
Cutter Material CR12
Drive Type Chain Drive
Speed 4m/min
Total Power 5.5+5.5KW
Voltage 380V 50Hz 3Phases

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

Double Layer PPGI / GI Glazed Sheet Roll Forming Machine


This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
In the production process of glazed tiles, metal sheets are usually supplied in the form of coils. The primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.

Hydraulic Pump Station
Double Layer PPGI / GI Glazed Sheet Roll Forming Machine
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.

Touch Screen Control Cabinet

Double Layer PPGI / GI Glazed Sheet Roll Forming Machine

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.

Feeding Table & Pre-Cutter

Double Layer PPGI / GI Glazed Sheet Roll Forming Machine

During the sheet feeding process, the feed table can play a certain buffering role. When the sheet is transferred from the external loading device to the feed table, the conveying device of the feed table can receive the sheet at a relatively slow speed, reducing the impact force of the sheet during the transfer process and avoiding damage to the feed port or internal components of the tile press.

Shaft & Roller

Double Layer PPGI / GI Glazed Sheet Roll Forming Machine

The shaft is the supporting base of the roller, which keeps the roller in the correct position and posture to ensure that it can stably press and shape the plate. Multiple groups of rollers are installed on the frame of the tile press through the shaft. The accuracy and strength of the shaft directly affect the concentricity and stability of the roller, and thus affect the forming quality of the glazed tile.

Pressing Section & Cutter

Double Layer PPGI / GI Glazed Sheet Roll Forming Machine

The material of blade is CR12.
With high strength, better hardenability and good wear resistance.

By rationally planning the cutting path and method, the cutter can minimize waste generation while ensuring the quality and size requirements of glazed tiles, maximize the utilization of raw materials, reduce production costs, and improve the economic benefits of the enterprise.
