Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine
Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine
Specifications
Brand Name :
HC
Model Number :
HC25-125-250
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
20set per month
Delivery Time :
20-30 work days
Packaging Details :
Main machine is nude，The workbench is packed with plastic stretch film
Material Type :
PPGI/GI
Material Thickness :
0.3-0.6mm
Material Width :
1250mm
Roller Stations :
18Stations
Roller & Shaft Material :
45# Steel Quenching and Plating
Diameter of Shaft :
Φ70mm
Cutter Material :
CR12
Drive Type :
Chain Drive
Speed :
15m/min
Total Power :
5.5+5.5KW
Voltage :
380v 50Hz 3phases
Description

Product Description
The double-layer tile pressing machine can produce two different specifications of tiles at the same time with its efficient production capacity, greatly shortening the production cycle and meeting the needs of rapid construction of industrial plants. Moreover, the tiles it produces are of reliable quality, with high dimensional accuracy after precise molding process, which can provide stable and durable roof covering for industrial plants and adapt to various climate and mechanical stresses that may be faced in industrial environments.

Main Technical Parameters

Material Type PPGI/GI
Thickness 0.3-0.6mm
Width 1250mm
Roller Stations 18Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ70mm
Cutter Material CR12
Drive Type Chain Drive
Speed 15m/min
Total Power 5.5+5.5KW
Voltage 380V 50Hz 3Phases

Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting

Component & Technical Parameters

Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine


This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm

Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.

Hydraulic Pump Station
Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.

Touch Screen Control Cabinet

Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine

The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.

Feeding Table & Pre-Cutter

Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine

The feed table provides a support platform for the plate to be processed, so that the plate can be placed stably. At the same time, the feed table is usually equipped with a conveying device, such as a roller or a conveyor belt, which can accurately feed the plate into the forming mechanism of the tile press at a set speed under the drive of the motor, ensuring that the plate maintains a linear motion during the feeding process, providing a stable input for the subsequent forming process.

Shaft & Roller

Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine

The shaft is an important supporting component of the tile press. It bears the weight of each roller and other related components to ensure that these components maintain a stable position relationship during the working process. At the same time, the shaft is also a key component of power transmission. By connecting with power devices such as motors and reducers, the power is transmitted to each roller, so that the roller can rotate at the set speed and direction, thereby realizing the processing of the plate.

Pressing Section & Cutter

Trapezoidal America PBR Steel Roof Panel Sheet Roll Forming Bending Machine

The cutter adopts a special design and material, which can make the cut flat and smooth without obvious burrs, flash or deformation during the cutting process.
