2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor
2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor
2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor
2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor
Specifications
Brand Name :
TISCHBEIN
Model Number :
TSO-10
Certification :
CE, ISO
MOQ :
1 Unit
Supply Ability :
5000 UNITS PER YEAR
Delivery Time :
25 DAYS
Packaging Details :
WOODEN BOX
Price :
US$10000-US$20000
Capacity :
450kg 630kg 800kg 1000kg 1250kg 1600kg 2000kg 2500kg
Speed :
1.0m/s 1.5m/s 1.75m/s 2.0m/s 2.5m/s
Drive :
Traction VVVF
Machine room :
Without machine room
Machine :
Permanent Magnet Sychronous Gearless Traction Machine
Door Protection :
Full Range of Infrared Light Curtain Protection
Decoration :
Glass cabin wall glass doors
Display of COP and HOP :
Dotmatrix LCD
Door opening :
Center opening side opening telescopic opening
HS Code :
8428101090
Description

2.0m/s traction panoramic elevator sightseeing elevator Observation elevator Glass elevator with gearless motor for hotel

The fresh new panoramic elevator is of the elegant and beautiful outline model, the extraordinarily distinguished grade. It helps you to appreciate the outstanding charm and luxurious manner of modern architectures. It complies with the energy-saving VVVF variable frequency drive and quietly bears the fully deducts the profound knowledge of TISCHBEIN elevator to modern urban life by the steady and comfortable travel experience, the unique style of popular outlook, the humane interface setting.

1. Specification

TISCHBEIN Machine Roomless Panoramic Elevator
Loading
( Kgs)		 Person Speed
( m/s)		 Roping Shaft Clear Inner Size
( W*D in mm)		 Car Clear Inner Size
( W*D*H in mm)		 Door Open
( W*H in mm)		 Pit Depth
( mm)		 Overhead Heigh
450 6 1.00 2:1 1800W*1700D 1000W*1200D*2250H 800W*2100H ≥1500 ≥4400
1.50 ≥1600 ≥4600
1.75 ≥1700 ≥4700
630 8 1.00 2:1 2000W*1800D 1100W*1400D*2250H 800W*2100H ≥1500 ≥4400
1.50 ≥1600 ≥4600
1.75 ≥1700 ≥4700
800 10 1.00 2:1 2200W*1800D 1350W*1400D*2250H 800W*2100H ≥1500 ≥4400
1.50 ≥1600 ≥4600
1.75 ≥1700 ≥4700
1000 13 1.00 2:1 2250W*2000D 1400W*1600D*2250H 900W*2100H ≥1500 ≥4400
1.50 ≥1600 ≥4600
1.75 ≥1700 ≥4700

2. Elevator Parts Main Components

We adopt newest technology and high quality components

VVVF permanent magnet Door Operator System

Permanent magnet sychronous gearless Traction Machine

One-piece Control Cabinet

The light curtain door protection

LED lighting system

Triple guards intelligent automatic rescuing

2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor

TSO-10 series panoramic elevator of compact layout and optimized space,is not restricted by building structures, which is flexibly applied to various vertical passenger transportation scenarios.

Space improvement 50%
The machine room area overlaps with the hoistway area and the height is reduced,which can save 50%area of the original machine room.The overall compact structure can provide wider car space and make the elevator riding capacious and comfortable.

Excellent carrying performance
Equipped with permanent magnet synchro-nous gearless drive and computer intelligent control system,it operates stably and securely with low noise.

2.0m/s Elevator Panoramic Sightseeing Elevator Observation Elevator Semi Round Cabin With Gearless Motor

TISCHBEIN ELEVATOR, TIED TO SAFETY. And welcome to contact us!
