GR2 Cylindrical Titanium Sintered Metal Powder Filter For Filtration Gases And Liquids
GR2 Cylindrical Titanium Sintered Metal Powder Filter For Filtration Gases And Liquids
Specifications
Brand Name :
ZYD
Model Number :
ZYD-Ti-Items
Certification :
ISO9001
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
L/, D/A, D/P, T/T, Western Union
Supply Ability :
10000 PCS per month
Delivery Time :
3-30 days
Packaging Details :
standard export case
Available Material :
Titanium, Nickel, Stainless steel
Wall Thickness :
2.0mm-5.0mm
Diameter :
OD10-150MM
Technique :
Sintering
Filtering Level :
T1-T9
Package :
Wooden case
Description

GR2 Cylindrical Titanium Powder Sintered Filter For Filtration Gases And Liquids

Features:

1. Working Temperature:-200—1000°C
2. Corrosion Resistance
3. High Filtering Efficiency
4. Metallic capacities, such as noise reduction, hot resistance, heat conduction, high strength and etc
5. Easy to welding and long working life
Filter Shape:
Could be cartridge filters, disc filters ,cup filters, cap filters, filter plate etc.

standard sintered filter cartridges size:

OD 10mm,20mm,30mm,40mm,50mm,60mm,70mm,80mm
Thickness of wall 1.0mm/2.0mm/3.0mm/4.0mm/5.0mm
Length 10",20",30",40"
Connectors DOE,SOE,Thread,Screw,Flange,220,222,226

Titanium powder sintering filter elements

Allow to usd in ≤300°C

Filtering level

Filtering precision

Um

Maximum Aperture

Um

Permeability

m3/h.m2.kpa

Thickness

mm

Compressivestrength

Mpa/cm2
T9 0.2 2.5 1.5 3 3.0
T8 0.5 4 3 3 3.0
T7 1 6 5 3 3.0
T6 2 10 15 3 3.0
T5 5 15 40 3 2.5
T4 10 30 120 3 2.5
T3 20 60 250 3 2.5
T2 30 100 500 3 2.5
T1 50 160 800 3 2.5

Application:

Separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries

GR2 Cylindrical Titanium Sintered Metal Powder Filter For Filtration Gases And Liquids

Why Choose Us

1. From raw material to final products,the unique number will be record. It is be tracted back to any process ,if any problem on final goods.

2. ISO9001 certificated,and the third party inspection avaiable on the products.

3. Our factory located in " Titanium Valley" in Baoji city, which has a strong supportinge equipment

4. Our sales are good at international standards, and global purchasing requirement. Good communicate and the best cooperator.
