Sputtering Target Chromium Cr 100x40mm Hot Isostatic Pressing
Sputtering Target Chromium Cr 100x40mm Hot Isostatic Pressing
Specifications
Brand Name :
CSTI
Model Number :
20221110
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
1piece
Price :
$55.00 - $150/pc
Payment Terms :
T/T, L/C
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
7~20 work days
Packaging Details :
Vacuum sealed package inside; export wooden case or carton outside
Material :
Chromium/Cr
purity :
99.5%~99.95%
Size :
φ100*40mm, φ150*30mm, φ155*30, φ80*40mm etc
Forming process :
hot isostatic pressing(HIP)
Shape :
rectangular target, arc target, ring target and large aspect ratio integrally formed tube target etc
Application :
decorative coating, tool coating, flat display coating, thin film solar industry, flat panel display industry, energy-saving glass industry, optical coating industry (such as automobile rearview mirror coating)
Description

The chromium sputtering target material is produced by the advanced hot isostatic pressing (HIP) process. sputtering target include rectangular target, arc target, ring target and large aspect ratio integrally formed tube target, etc., with controllable purity and density, and fine and uniform grains , Long service life and other advantages.

Purity: 99.5%~99.95%;

Forming process: hot isostatic pressing(HIP);

Conventional size: ID55*OD70*L, ID125*OD153*L, φ100*40mm, φ150*30mm, φ155*30, φ80*40mm, etc.;

Application: decorative coating, tool coating, flat display coating, thin film solar industry, flat panel display industry, energy-saving glass industry, optical coating industry (such as automobile rearview mirror coating), etc.

Product performance
Purity 99.5 99.95
Density g/cm3 ≥7.12 ≥7.12
Grain size/μm ≤100 ≤100
Total content of metallic impurities/ppm ≤5000 ≤500
Thermal conductivity/W/m.K 60 100
Coefficient of thermal expansion/1/K 8×10-6 8×10-6
Size/mm Planar target ≤1600×500 ≤1600×500
Rotating target Integral formingby HIP
Length≤4000
Thickness≤15		 Integral formingby HIP
Length≤4000
Thickness≤15

Chromium 2N5 (Trace elements)PPM ≥7.12g/cm3

Composition Fe Al Si C S O N
Standard ≤1500 ≤1200 ≤1500 ≤200 ≤50 ≤1400 ≤300
Test values 980 300 600 62 50 1200 200

Chromium 2N8 (Trace elements)PPM ≥7.12g/cm3

Composition Fe Al Si C S O N
Standard ≤800 ≤300 ≤400 ≤200 ≤50 ≤1000 ≤100
Test values 740 78 92 84 50 340 30

Chromium 3N (Trace elements)PPM ≥7.12g/cm3

Composition Fe Al Si C S O N
Standard ≤500 ≤100 ≤150 ≤150 ≤30 ≤500 ≤100
Test values 290 47 80 90 28 450 50

Chromium 3N5 (Trace elements)PPM ≥7.12g/cm3

Composition Fe Al Si Cu Ｎi C S O N
Standard ≤100 ≤50 ≤50 ≤10 ≤50 ≤50 ≤30 ≤150 ≤80
Test values 50 45 40 7 10 24 27 137 30

Other targets can also be supplied

Item Purity Density Coating color Shape Standard size
Titanium Aluminum(TiAl) Alloy target 2N8-4N 3.6-4.2 Rose gold/coffee/champagne gold cylinder/planar (D)70/100*(H)100-2000mm

solar photovoltaic industry, decorative coatings industry, flat
panel display industry, architectural glass/automotive glass industry, flexible winding coating industry, optical data
storage industry, optical communication/optical industry and magnetic data storage as well as semiconductor industry
Pure chrome (Cr)target 2N7-4N 7.19 gun grey/black cylinder/planar (D)70/100*(H)100-2000mm
Pure Titanium(Ti) target 2N8-4N 4.51 gold/rose gold/blue/rainbow/light black/gun grey cylinder/planar (D)70/100*(H)100-2000mm
Pure Zirconium(Zr) target 2N5-4N 6.5 light gold cylinder/planar (D)70/100*(H)100-2000mm
Pure Aluminium(Al) target 4N-5N 2.7 silver cylinder/planar (D)70/100*(H)100-2000mm
Pure Nickel (Ni) target 3N-4N 8.9 nickel cylinder/planar (D)70/100*(H)100-2000mm
Pure Niobium (Nb) target 3N 8.57 white cylinder/planar (D)70/100*(H)100-2000mm
Pure Tantalum(Ta) target 3N5 16.4 black/pure cylinder/planar (D)70/100*(H)100-2000mm
Pure Molybdenum (Mo) target 3N5 10.2 black cylinder/planar (D)70/100*(H)100-2000mm
Remarks: Size can be customizaed according to specical requirements

Product Advantage

01 High chemical purity

02 Low gas content

03 Close to 100% density

04 Uniform grains

05 Dense and homogeneous inner structure

Application Field

Solar photovoltaic industry
Decorative coatings industry
Flat panel display industry
Architectural glass/automotive glass industry
Flexible winding coating industry
Optical data storage industry
Optical communication/optical industry
Magnetic data storage as well as semiconductor industry
