Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Growatt
Model Number :
10kw
Input Voltage :
120-430Vdc
Output Voltage :
230V AC±5%
Output Current :
15.2A AC
Output Frequency :
50/60(HZ)
Output Type :
Single, Triple
Size :
590*470*210mm
Type :
DC/AC Inverters
Inverter Efficiency :
98%
Certificate :
CE/ISO9001
Warranty :
1year
Weight :
16
Product name :
10kw Hybrid Solar Inverter
Application :
Home Appliance
Inverter type :
On-grid Solar Power Inverter
Battery type :
Lead Acid \ Lithium \ Gel
Protection :
Overload
Keyword :
Inverter Solar
Color :
Customized Color
OEM :
Accepted
Display :
LCD Display
Controller type :
MPPT Solar Controller
Packaging Details :
We will according your product select the most suitable packaging according to the quantity.
Port :
Yiwu
Supply Ability :
1000 Box/Boxes per Week
Price :
$389.60/boxes 1-299 boxes
Description
Products Description
Datasheet
SPF 3500 ES
SPF 5000 ES
Battery Voltage
48VDC
Battery Type
Lithium/Lead-acid
INVERTER OUTPUT
Rated Power
3500VA/3500W
5000VA/5000W
Parallel Capabillty
Yes, 6 units maximum
AC Voltage Regulation (Battery Mode)
230VAC±5%@50/60HZ
Surge Power
7000VA
10000VA
Efficiency(Peck)
93%
Waveform
Pure sine wave
Transfer Time
10ms typical,20ms Max
SOLAR CHARGER
Maximum PV Array Power
4500W
6000W
MPPT Range@Operating Voltage
120VDC-430VDC
Number of Independent MPPT Trackers/Strings Per MPP Tracker
1/1
Maximum PV Array Open Circuit Voltage
450VDC
Maximum Solar Charge Current
80A
100A
AC CHARGER
Charge Current
60A
80A
AC Input Voltage
230VAC
Selectable Voltage Range
170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range
50HZ/60HZ (Auto Sensing)
PHYSICAL
Protection Degree
IP20
Dimension（W/H/D）
330/485/135MM
330/485/135MM
Net Weight
11.5kgs
12kgs
OPERATING ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non-condensing)
Altitude
<2000m
Operating Temperature
0°C-55°C
Storage Temperature
-15°C-60°C
Working Modes Applications
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Product Details
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Company Profile
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter
Growatt SPF 3500-5000ES 48V Solar Panels Inverter 5000W 230V Off Grid Solar Hybrid Inverter With MPPT Pure Sine Wave Inverter

1,Q:Why your quotation is higher than other suppliers? A:In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter! .............................................................................................................................................................. 2,Q:How many categories does it have according to the output waveform ? A:Type one: Modified Sine Wave inverter, which uses PWM pulse width modulation to generate modified sine wave. Due to the usage of intelligent dedicated circuit and high power field effect tube, it greatly reduces the power loss and increases the soft-start function, effectively ensuring the reliability of the inverter. If the power quality is not highly demanded, it is able to meet the needs of most electrical equipment. But it still exists 20% harmonic distortion problems when running sophisticated equipment, can also cause high-frequency interference to radio communications equipment. This kind of inverter can meet the basic needs of most of our power, high efficiency, small noise, moderate price, and thus become the mainstream products in the market. Type two: Pure Sine Wave inverter, which adopts isolated coupling circuit design, high efficiency, high stability of the output waveform, high-frequency technology, small in size, suitable for all kinds of load, can be connected to any common electrical devices and inductive load devices (such as refrigerators, electric drill, etc.) without any interference (eg: buzz andTV noise). The output of pure sine wave inverter is the same as the grid tie power we daily used, or even better, because it does not exist grid tie electromagnetic pollution. .............................................................................................................................................................. 3,Q:Is the output voltage of our inverter stable ? A:Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Actually the output voltage is quite stable. Here we need make a especial explanation : many customers found it is unstable when using conventional multimeter to measure voltage. We can say the operation is incorrect. Ordinary multimeter can only test pure sine waveform and calculate datas. .............................................................................................................................................................. 4,Q:What is a resistive load appliances? A:Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully. .............................................................................................................................................................. 5,Q:What is the inductive load appliances? A:It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them. .............................................................................................................................................................. 6,Q:What should be noticed when installing inverter? A:Put the product in a place where is well ventilate,cool, dry and water-proof. Pls do not stress and do not put foreign objects into the inverter.Rember to turn on the inverter before turn on the appliance.
