TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
Specifications
Place of Origin :
CHINA
Brand Name :
TOBO
Certification :
LR,BV,SGS,BIS,DNV,CRN,ABS,TUV，
Model Number :
TP310/TP347/TP321/TP304H
MOQ :
1PCS
Price :
1USD
Packaging Details :
WOODCASE or PLATE
Delivery Time :
0-30days
Payment Terms :
TT/LC
Supply Ability :
300000T/Year
Description

ASTM A312 / A213 Cold Drawn Seamless Pipe, TP304 / 304L Stainless Steel Tubing

Typical 304 Stainless Steel

Type 304 stainless steel is the most common austenitic chromium-nickel
stainless steel and is a variation of the classic 18-8 stainless.
Its properties provide corrosion resistance to a wide range of atmospheric,
chemical, textile, petroleum, and food industry exposures.

Typical 304 Chemical Composition /%

Material

C

Si

Mn

P

S

Ni

Cr

Mo

N

Ti

304

≤0.08

≤0.75

≤2.00

≤0.045

≤0.03

8.0-10.0

18~20.0

/

/

/

Typical 304 Mechanical property

Material

Yield
strength
σ0.2/Mpa

Tensile
strength
σb/Mpa

Elongation
δ5/%

Hardness Test
HB HRB

304

≥205

≥515

≥40

≤217

≤95



Stainless Steel Seamless Pipe:
1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include “Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
8.MTC: BWSS Official Original MTC paper will be supplied for each order.
APPLICATIONS FIELD :

ndustry

Applications

Industry

Applications

Chemical

Heat Exchanger,Boiler

Sugar

Evaporators, Condensers, Driers

Petrochemicals

Condensers

Automobiles

Muffler Tubes Hydraulic Tubing

Refineries

General Piping

Construction

Architectural Furniture

Fertilizers

Pressure Vessels

Pharmaceuticals, Dairy, Food & Beverages

Machineries Process Piping

Paper & Pulp

Industrial Equipments

Submersible Pumps

Pump Casing Applications

Engineering

Machineries Instrumentation Tubing


Specifications:

Mechanical Property

Material Item

304

304L

304

316L

Top Technology

Tensile Strength

≥520

≥485

≥520

≥485

Yield Strength

≥205

≥170

≥205

≥170

Extension

≥35%

≥35%

≥35%

≥35%

Hardness (HV)

<90

<90

<90

<90

TOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel TubingTOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel TubingTOBO STEEL Group ASTM A312 A213 Cold Drawn Seamless Pipe , TP304 304L Stainless Steel Tubing
