Precision Rolled Pure RA Copper Foil Supply To Samsung Innox SK Company
Precision Rolled Pure RA Copper Foil Supply To Samsung Innox SK Company
Precision Rolled Pure RA Copper Foil Supply To Samsung Innox SK Company
Precision Rolled Pure RA Copper Foil Supply To Samsung Innox SK Company
Specifications
Brand Name :
TOBO
Model Number :
CIVEN TR RA CU FOIL 001
Certification :
SGS BV
Place of Origin :
China
MOQ :
1KG
Price :
1-100 USD
Payment Terms :
T/T OR L/C
Supply Ability :
50000KG
Delivery Time :
10-100 days depending on the quantity
Packaging Details :
wooden case or as per the customer's request
Description
Detailed Product Description
MATERIAL: C11000 GRADE PURE COPPER APPLICATION: LAMINATING , SHIELDING , AND SO ON
SPECIFICATION: TO BE ORDERED MAX WIDTH: 650MM
MIN THICKNESS: 9UM FAMOUS CUSTOMER: SAMSUNG , LG

Graphene Film

  • Growth method: CVD synthesis
  • Appearance (color): Transparent
  • Transparency: > 97%
  • Appearance (form): Film
  • Coverage: > 95%

Raw Material

Name GB ALLOY NO. SIZE (mm)
(ISO) (ASMT) (JIS) (BIS) (DIN)
Copper Foil T2 Cu-ETP C11000 C1100 C101 R-Cu57 Thickness: 0.006-0.1 /Max Width: 650

FPC T2 high flex rolled copper foil properties (IPC-6542)

Item Unit Parameters
12μm 18μm 25μm 35μm 70μm
Mass per unit(±5%) g/m² 105 160 300 400 445
Cu+Ag % ≥99.99
Temper H O,H O,H O,H O,H
Surface roughness Ra μm 0.13 0.12 0.1 0.08 0.08
Rz μm 1.3 1.0 0.8 0.74 0.76
Tensile strength Normal Temp /23℃ N/mm² ≥430 ≥450 ≥450 ≥450 ≥450
High Temp /220℃ N/mm² ≥140 ≥150 ≥170 ≥210 ≥220
Elongation Normal Temp /23℃ % ≥1.5 ≥3.0 ≥4.0 ≥4.2 ≥4.5
High Temp /220℃ % ≥8 ≥10 ≥18 ≥28 ≥30
Fatigue Resistance (annealed) % 65 65 65 65 65
Maximum resistivity Ωmm2/m 0.0181
Electrical conductivity % ≥98.3%
Film and adhesive layers

Instant Temp.

300℃/10s

Film and adhesive paste after transient

temperature without blistering delamination.
Anti oxidation H.T.(200℃) Minute Won’t Change the Color within 60 minutes
Pinhole test results piece/ m² Pinhole area more than 0.5 mm²,0.005 piece/ m²

Note:

1. Above figures based on the material with 0.05mm in thickness and 600mm in width.

2. Normally, Copper, cobalt and nickel is coated on the rough surface.

3. Testing method follows our company standard.
