Inconel 825 / UNS N08825 / W.Nr.2.4858 Inconel Tubing Steel Pipe ASTM B161163 165 167 407 444 677
Inconel 825 / UNS N08825 / W.Nr.2.4858 Inconel Tubing Steel Pipe ASTM B161163 165 167 407 444 677
Inconel 825 / UNS N08825 / W.Nr.2.4858 Inconel Tubing Steel Pipe ASTM B161163 165 167 407 444 677
Inconel 825 / UNS N08825 / W.Nr.2.4858 Inconel Tubing Steel Pipe ASTM B161163 165 167 407 444 677
Specifications
Brand Name :
TOBO
Model Number :
Inconel825 / UNS N08825
Certification :
SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin :
China
MOQ :
1pcs
Price :
1USD
Payment Terms :
T/T
Supply Ability :
3,0000pcs per month
Delivery Time :
10-100 days depending on quantity
Packaging Details :
PLY-WOODEN CASE OR PALLET
Description
Detailed Product Description
Material Grade: Inconel825 / UNS N08825 Outer Diameter: 6mm-920mm
Standard: ASTM B161163 165 167 407 444 677 Surface: Annealed And Pickled
Type: Stainless Steel Seamless Tube / Tubing Wall Thickness: 0.6mm-50mm

Inconel825 / UNS N08825 / W.Nr.2.4858 Steel Pipe ASTM B161163 165 167 407 444 677

Features:
1) Specifications: OD: 10- 273 mm and THK: 1 - 20 mm
2GradesAlloy200,Monel400,lnconel600,lncoloy800/H/HT,Alloy825

Incoloy 825 is a nickeliron chromium alloy with titanium, copper, and molybdenum. Incoloy825's chemical

composition provides great resistance to many corrosive environments, such as pitting, crevice corrosion,

intergranular corrosion, and stress corrosion cracking. Incoloy 825 has good mechanical properties from

moderately to high temperatures. The hotworking range for Incoloy 825 is 1600 to 2150° F. The material

has good weldability by all conventional processes.Available forms are seamless pipe, welded pipe,

seamless tube, welded tube, bar, wire, sheet, plate, forgings, pipe fittings and flanges.

Specifications

Features:
1) Specifications: O.D.: 6mm – 630mm / DN 6 – 600 / NPS 1/8’’ – 24’’

W.T.: 0.9mm – 40mm Sch 5S – Sch XXS

Length: ≤ 24000 mm

2)Austenitic steel: OD:6mm to 630mm,THK:0.8mm--30mm

3)Duplex/Super Duplex/Nickel Alloy steel: OD:6mm--273mm,THK:1mm--20mm

4)Butt-welding Elbow/Tee/Reducer/Cap:3/8"--48" THK:SCH 5---SCH 160

5) Grades:Hastelloy:Hastelloy/B/C/G.
Nickel Alloy:Alloy200,Monel400,lnconel600,lncoloy800/H/HT,Alloy825,Allo20,Alloy28.

*Other Material Also Available After Negotiation.

6) Made according to the standards of ASTM B161,163,165,167,407,444,677, etc.

7)Process Method: Cold Drawn/Cold Rolled

8)Surface Finish:Annealed/Manual polished/Mechanical Polished

9)Delivery Condition:Solution Annealed,Bright Annealed,Pickled with Beveled End or Plain End.

10)Packing: Un-woven-knittings bags or Wooden cases or as your requirments.

11)Testing: Eddy current / hydrostatic/ Ultrasonic/ Intergranular Corrosion available

12)Certificate:ISO9001:2000-Lloyds,ISO9001:2008-TUV,PED97/23/EC & AD2000-W0-TUV.GOST,RTN,

Shipbuilding Certificates(ABS,CCS,KR,GL,NK,DNV,LR and BV) etc

10) Chemical Composition

Grade C max Si max Mnmax S max P max Cr Ni Mo Ti
200 0.15 0.35 0.35 0.01 99min
400 0.30 0.50 2.00 0.024 63min
600 0.15 0.50 1.00 0.015 14-17 72min
625 0.10 0.50 0.50 0.015 0.015 20-23 58min 8-10 0.40max
800 0.10 1.00 1.50 0.015 0.03 19-23 30-35 0.15-0.60
825 0.05 0.50 1.00 0.03 19.5-23.5 38-46 2.5-3.5 0.6-1.2
800HT 0.10 1.00 1.50 0.015 19-23 30-35 0.15-0.60
