Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
Specifications
Brand Name :
TOPELE
Model Number :
GI cable trunking
Certification :
ISO
Place of Origin :
Zhejiang ,china
MOQ :
100PCS
Price :
negotiable
Payment Terms :
T/T, L/C at sight
Supply Ability :
200 tons one month
Delivery Time :
20 days for one 20ft container
Packaging Details :
10pcs per bundles with white plastic bag
Material :
steel
Surface treatment :
powder coating，hot dipped galvanized, polishing, Electro zinc Plate
apprication :
project
Color :
Silver， black or comerization
thickness :
1.2,mm-3.0mm
Length :
2000mm，30000mm or costomerization
Accept :
OEM/ODM Service，Accept trial orders
Product type :
solid through
Description

Perforated GI Cable Trunking Stainless steel Pre-galvanized / Zinc Plated Electrical Cable Tray

Description:

GI CABLE TRUNKING

Thickness: 1.0mm,1.2mm,1.5mm,2.0mm

Finish: pre-galvanized, hot dipped galvanized, plastic-spray

Length: 2.9meters, 3meters, as client’s request

Electro zinc plated – for indoor use to BS EN 12329-2000, 12microns thick

Powder coated - for indoor use to JG/T3045-1998, between 6 and 10 microns thick

Hot Dipped Galvanized – for outdoor use to BS EN 1461-1999, between 60 and 80 microns thick

Electrolytic Polishing – for stainless steel use

Specification:

width*height

50x50mm;75x50mm;75x75mm;100x50mm;100x75mm;100x100mm;150x50mm;150x75mm;

150x100mm;150x150mm;200x100mm;300x150mm;400x150mm;600x200mm;800x200mm

Competitive Advantage:

The advantages of our GI Cable Trunking :

1. Low cost, significant cost savings compared to standard traditional tray products.

2. Light in weight, wide range of sizes.

3. Fast heat dispersion.

4. Strong enough to withstand short circuits. Provides strength, rigidity without additional hardware.

5. Adapts to difficult architectural designs to accommodate changes in direction and elevation of cable runs.

6.Flexible, easy and fast installation. Design allows cable exit or entry at any point.

7. Cables can be secured to clamps or ties.

8.Various hardware accessories available to fix, support and install.

9. Safe smooth edge design to protect cable.

10.Easy for line check and cleaning , easy maintained.

Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter

Powder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 MeterPowder Coated Electrical Cable Tray GI Cable Trunking Stainless Steel 200 Meter
