N Channel Transistor Discrete Semiconductor Devices SIHF10N40D-E3 Power Mosfets
N Channel Transistor Discrete Semiconductor Devices SIHF10N40D-E3 Power Mosfets
N Channel Transistor Discrete Semiconductor Devices SIHF10N40D-E3 Power Mosfets
N Channel Transistor Discrete Semiconductor Devices SIHF10N40D-E3 Power Mosfets
Specifications
Brand Name :
Vishay Semiconductor
Model Number :
SIHF10N40D-E3
MOQ :
1 piece
Payment Terms :
T/T
Delivery Time :
2~8 workdays
Brand :
Vishay Semiconductor
Certificate :
/
Model :
SIHF10N40D-E3
MOQ :
1 pc
Price :
Negotiated
Delivery :
2~8 workdays
Payment :
T/T
Description

Product Technical Specifications

N Channel Transistor Discrete Semiconductors SIHF10N40D-E3 Power Mosfets

EU RoHS Compliant
ECCN (US) EAR99
Part Status Active
HTS 8541.29.00.95
Automotive No
PPAP No
Product Category Power MOSFET
Configuration Single
Channel Mode Enhancement
Channel Type N
Number of Elements per Chip 1
Maximum Drain Source Voltage (V) 400
Maximum Gate Source Voltage (V) ±30
Maximum Gate Threshold Voltage (V) 5
Maximum Continuous Drain Current (A) 10
Maximum Gate Source Leakage Current (nA) 100
Maximum IDSS (uA) 1
Maximum Drain Source Resistance (MOhm) 600@10V
Typical Gate Charge @ Vgs (nC) 15@10V
Typical Gate Charge @ 10V (nC) 15
Typical Input Capacitance @ Vds (pF) 526@100V
Maximum Power Dissipation (mW) 33000
Typical Fall Time (ns) 14
Typical Rise Time (ns) 18
Typical Turn-Off Delay Time (ns) 18
Typical Turn-On Delay Time (ns) 12
Minimum Operating Temperature (°C) -55
Maximum Operating Temperature (°C) 150
Supplier Package TO-220FP
Pin Count 3
Standard Package Name TO-220
Mounting Through Hole
Package Height 16.12(Max)
Package Length 10.63(Max)
Package Width 4.83(Max)
PCB changed 3
Tab Tab
Lead Shape Through Hole
Part number SIHF10N40D-E3
Base part number SIHF10N40
EU RoHS Compliant with Exemption
ECCN (US) EAR99
Part Status Active
HTS 8541.29.00.95
