Specifications
Brand Name :
Texas Instruments
Model Number :
TPS2065DDBVR
MOQ :
1 piece
Payment Terms :
T/T
Delivery Time :
2~8 workdays
Brand :
Texas Instruments
Certificate :
/
Model :
TPS2065DDBVR
MOQ :
1 pc
Price :
Negotiated
Delivery :
2~8 workdays
Payment :
T/T
Description
Latest Non Inverting PMIC Chip Texas Instruments TI TPS2065DDBVR
Detailed Product Description
D/c: Originals Type: Drive IC
Shipping By: DHLUPSFedexEMSHK Post Datesheet: Pls Contact Us
Shipping Ways: DHL FEDEX UPS EMS TNT
High Light:

Non Inverting PMIC Chip

,

Texas Non Inverting PMIC Chip

,

Drive Non Inverting PMIC Chip

Power Management ICs Texas Instruments/TI TPS2065DDBVR

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Sufficient
Fake Threat In the Open Market 64 pct.
Popularity High
MSL Level 2 (1 Year)
Manufacturer Pack Quantity 3,000
Mounting Style Surface Mount
Supplier Device Package SOT-23-5
Manufacturer Package SC-74A, SOT-753
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Rds On (Typ) 96mOhm
Temperature Range - Operating -40°C ~ 85°C
Voltage - Supply (Vcc/Vdd) Not Required
Voltage - Load 4.5V ~ 5.5V
Win Source Part Number 800727-TPS2065DDBVR
Input Type Non-Inverting
Output Type N-Channel
Output Configuration High Side
Switch Type General Purpose
Packaging Reel
Manufacturer Texas Instruments
Current - Output (Maximum) 1A
Interface On/Off
Number of Outputs 1

Features for the TPS2065D

  • Single Power Switch Family
  • Rated currents of 1 A
  • ±20% Accurate, Fixed, Constant Current Limit
  • Fast Overcurrent Response: 2 µs
  • Deglitched Fault Reporting
  • Output Discharge
  • Reverse Current Blocking
  • Built-in Soft Start
  • Ambient Temperature Range: –40°C to 85°C
  • UL Listed and CB-File No. E169910

Description for the TPS2065D

The TPS2065D power-distribution switch family is intended for applications such as USB where heavy capacitive loads and short circuits are likely to be encountered. The device can continuously deliver up to 1 A output current.

The TPS2065D limits the output current to a safe level by operating in a constant-current mode when the output load exceeds the current limit threshold. This provides a predictable fault current under all conditions. The fast overload response time eases the burden on the main 5-V supply to provide regulated power when the output is shorted. The power-switch rise and fall times are controlled to minimize current surges during turnon and turnoff.
