Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
Specifications
Brand Name :
TOPLED
Model Number :
Indoor p2
Certification :
CE, ROHS, FCC, ISO9001, ISO14001
Place of Origin :
Guangdong
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SQM/Month
Delivery Time :
15-20 Working days
Packaging Details :
Wooden case, flight case, honeycomb.
Brightness :
400-1000
Scan Method :
1/30
Module Resolution :
60*45dots
Module Size :
120*90mm
Cabinet Size :
480*540mm
Usage :
Video
Description

120*90 Dots Indoor High Resolution P2 Small Pixel Pitch LED Display

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet

Features:

1.IC: By using high-end PWM chip ICN2053 to guarantee 16 gray-scale levels and refreshing of 3840HZ. Moreover, it can make the video more vivid and smooth.

2.Eliminating-shadow-line IC can completely clear off shadow in situations where current open or close.

3.By using Sn62.8/Pb36.8/Ag0.4 to improve stability of the soldered dots and reduce defects rate.

4.By using special PCB board to keep the uniformity of the module.

Specification

Name Parameter
Pixel Pitch(mm) 2mm
Physical Density 250,000
LED Configuration 1RGB
LED type SMD1515
Module Size 120×90
Module Resolution 60×45
Module Power Consumption 27W
Driving Mode Constant Current IC
Scanning Mode 1/30
Horizontal Viewing Angle 140
Vertical Viewing Angle 140
Brightness 1200
Grey Scale 16bit
Refresh Rate >3840
Cabinet Resolution 240×270
Cabinet Max Consumption 160
Cabinet Average Power Consumption 50
Cabinet Size 480×540
Cabinet Weight(kg) 8kg
Cabinet Thickness 85mm
Cabinet Material Iron/Aluminum
Color >16.7
Input Voltage AC 110V~220V +/-10%
Frame Frequency 60
Protection Level IP43
Working Temperature(℃) -40° -+65°
Storage Humidity Range(RH) 10%~90%

Aging Test

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panelHot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel

Hot sale HD indoor p2 led display screen with die-casting aluminum cabinet P2 Led panel
