ODM Indoor Advertising Led Light Poster P2.5 P3 Smart Led Poster
2. The LED screen has the advantages of high refresh, high brightness, high contrast of color,
and the playback effect is superior to the traditional LCD screen.
3. Support SD card and U disk playback media, stored program files can be played in a loop.
4. Support WIFI and 3G/4G mode for maintenance and update of programs.
5. It can be set to automatically turn on and off every day, without manual maintenance.
6. Support cluster play and management, agree that the cluster mirror screen can agree to design
and update programs, saving time and effort.
7. The cabinet structure is designed with a modular frame and a metal body for easy installation,
disassembly and maintenance.
8. The exterior of the cabinet is equipped with an acrylic plate to protect the screen body.
Applications:
Shopping Mall
Poster LED Screen are widely used in display activities in shopping malls, without installation, ,convenient transportation, and can be played offlineAmong of them, P2-P3 is the most popular pixel pitch, with high definition, and in terms of size, our company comprehensively considered the display effect and transportation, and chose 640*1920mm. The best effect is highlighted to the greatest extent
Showing Room
Usually used in the company's front desk or exhibition hall, to broadcast company-related information or product information and videos to facilitate visiting customers to quickly understand the company and products
Exhibitions
Use multiple cascading methods to connect together to play the same or different screens to display the company's products and information, or randomly place poster screen. Maximize the effect and increase the attractiveness of the booth.
Specifications | | | | | ||||
Model | P2.5 | P2.5 | P3 | P3 | ||||
Pixel Pitch | 2.5mm | 2.5mm | 3mm | 3mm | ||||
Application | Indoor | | | | ||||
LED Configuration | SMD2121 | SMD2121 | SMD2121 | SMD2121 | ||||
Pixel Density | 160,000dots/㎡ | 160,000dots/㎡ | 111,111dots/㎡ | 111,111dots/㎡ | ||||
Module size | 160X160mm | 160X160mm | 192X192mm | 192X192mm | ||||
Module Resolution | 64X64dot | 64X64dot | 64X64dot | 64X64dot | ||||
Cabinet Size | 640X1920X38mm | 960X1920X38mm | 576X1920X38mm | 768X1920X38mm | ||||
Cabinet Resolution | 256X768dots | 384X768dots | 192X640dots | 256X640dots | ||||
Cabinet Weight | 35kg | 50kg | 30kg | 40kg | ||||
IP Rating ( front/back) | IP40 | IP40 | IP40 | IP40 | ||||
Brightness Intensity | ≥1000cd/㎡ | ≥1000cd/㎡ | ≥1000cd/㎡ | ≥1000cd/㎡ | ||||
Viewing Angle | 140° | 140° | 140° | 140° | ||||
View Distance | >2m | >2m | >3m | >3m | ||||
Max./Avg. Power Consumption(W/m²) | 900W/300W | 1500W/500W | 800W/260W | 1100W/360W | ||||
Refresh Frequency | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ | ||||
Control Mode | Synchronous display with control PC by DVI | | | | ||||
Operation Power | AC100/240 50/60HZ | | | | ||||
Operating Condition | - 20℃~+50℃, 10~90% RH | | | |
