76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
Specifications
Place of Origin :
China
Brand Name :
TRT or OEM
Certification :
CE,CB
Model Number :
TRT-30php
MOQ :
1
Price :
Negotiable
Packaging Details :
plywood
Delivery Time :
15-20 days
Payment Terms :
TT
Supply Ability :
2000
Description

Model TRT-100PHPV TRT-120PHP TRT-200PHP TRT-240PHP
Metel plate Galvanized steel/Spray/Gray/White/ 304 Stainless Steel
Body size(L*W*H) 1500*800*1560 1850*1000*1950 2000*1100*2080
Compressor Copeland
Refrigerant R407C
Power Supply 380V/50Hz
Condenser Titanium tube heat exchanger
Gas-liquid separator KFR120WLG-A*2 KFR120WLG-A*2 KFR120WLG-A*4 KFR120WLG-A*4
Four-way Valve SHF-20A-46*2 SHF-20A-46*2 SHF-20A-46*4 SHF-20A-46*4
Expansion Valve 3.2*2 3.2*2 3.2*4 3.2*4
AC contactor (220V-25A)*2 (220V-32A)*2 (220V-25A)*4 (220V-32A)*4
Motor/ Fan Blade YWF.A6S-550S-5DIA00*2 YWF.A6S-550S-5DIA00*2 YWF.A6S-600S-5DIA00*2 YWF.A6S-630S-5DIA00*2
Controller Double System Double System Four System Four System
Low Pressure Switch 0.05/0.15MPa 0.05/0.15MPa 0.05/0.15MPa 0.05/0.15MPa
High Pressure Switch 2.4/3.0MPa 2.4/3.0MPa 2.4/3.0MPa 2.4/3.0MPa
Power Line 3*10mm2+2*4mm2 3*10mm2+2*4mm2 3*16mm2+2*6mm2 3*16mm2+2*6mm2
Packing Polywood Packing Polywood Packing Polywood Packing Polywood Packing
Rated Heating Capacity(kW) 38 44 76 86
Input Power(kW) 7.2 8.4 14.4 16.8
Rated Current(A) 16 18 32 36
COP 5.28 5.24 5.28 5.12
Rated outlet water temperature(℃) 28 28 28 28
Max outlet water temperature(℃) 40 40 40 40
Water Flow (L/H) 8168 9458 16336 18486
Waterproof Grade IPX4 IPX4 IPX4 IPX4
Anti-electric shock Rate I I I I
Noise(dB(A)) ≤66 ≤68 ≤68 ≤72
Net Weight/ Gross Weight(kg) 280/295 372/412 482/532 582/642
Pipe size/ Inner diameter(mm) DN32 DN50 DN50 DN65
Remark: Constant water temperature 28℃, Dry bulb temperature 20℃, Wet bulb temperature15℃.

Description:

TRT Pool Heat Pump provides the maximum energy efficiency and reliability. Working efficiently, the heat pump units absorb another 6 times of free heat from the ambient environment, and transfer it to the pool water, which makes the heating process ecological and cost saving.

76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool76 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
