95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with
Specifications
Place of Origin :
China
Brand Name :
TRT or OEM
Certification :
CE,CB
Model Number :
TRTN180HTASHP
MOQ :
1
Price :
Negotiable
Packaging Details :
plywood
Delivery Time :
15-20 days
Payment Terms :
TT
Supply Ability :
1000 PCS a month
Description

With 95 oC outlet water, TRT High Temperature Water Heaters which adopt EVI compressor are the best choice for your special requirements. These units are energy efficient and environmentally friendly. They are the ideal substitutes for the traditional boilers.

Model NO.TRT-080H-ASHPTRT-160H-ASHPTRT-180H-ASHP
configurationMetal plateGalvanized steel/Spray/Gray or White
Unit Siz (W*D*H) MM 800*800*10701500*800*15601500*800*1560
Compressor 1Copeland ZW34KA*1Copeland ZW72KA*1Copeland ZW72KA*1
Compressor 2Copeland ZW61KA*1Copeland ZW125KA*1Copeland VR144KS*1
RefrigerentSpecial Mixed Gas
Power Supply380V/50Hz/3Phase380V/50Hz/3Phase380V/50Hz/3Phase
CondenserShell and TubeShell and TubeShell and Tube
155HD-090*1155HD-090*2155HD-090*2
Liquid Storage Tanktogether with shell and tube heat exchanger
Gas-liquid separatorLF8W5A-03A*1LF8W5A-03A*1KFR120WLG-A*1
Four-way Valve SHF-11-45D1*1 SHF-20A-46*1 SHF-20A-46*1
Thermostatic expansion valveDanfoss 3RTDanfoss 6RTDanfoss 6RT
AC contactor18A*225A+32A25A+32A
ControllerDual systemDual systemDual system
Low Pressure Switch0.05/0.15MPa0.05/0.15MPa0.05/0.15MPa
High Pressure Switch2.4/3.0MPa 2.4/3.0MPa 2.4/3.0MPa
Power Line4*6mm24*10mm24*10mm2
packing Polywood packing
parameterHeating capacity (kW) 12.625.228.5
Input power(kW) 61213.5
rated current (A) 142630
COP2.102.102.11
Rated outlet water Temp(℃)909090
Max outlet water Temp(℃)959595
Protection gradeIPX4IPX4IPX4
Anti-electric shock RateIII
Noise(dB(A))≤55≤55≤58
N.W /G.W(kg)220/230340/350360/370
water pipe size (mm)DN25DN32DN32
Testing conditon: Dry bulb/ Wet bulb :20℃/ 15 ℃；initial inlet water Temp of 15℃,final outlet water Temp of 90℃
Remarks: The final outlet temperature can be over 90℃ on condition of ambient temperature of above 5℃;The final outlet temperature can be over 95℃ on condition of ambient temperature of above 10℃.


95℃ hot water High temperature air source heat pump with


Description

  1. Environmental friendly and safe

Electric parts and water system is completely cut off, ensuring security water use, no pollution to the atmosphere
and free of greenhouse effect and it is the safest water heater

  1. Wide climatic zone adaptability

Our heat pumps with special designing possess better climatic adaptability, can work from -25℃ to 43℃.

  1. Energy-saving

Heat pump water heater is a high efficient transferring heating equipment which is driven by electricity.
The operating cost is only 1/4 of electric water heater, 1/3 of gas water heater.

  1. Automatic intelligent control system

Adopting intelligent computerized automatic control system, no manual cost, easy to operate, convenient, make
heat pump work safely and reliably.Control panel with modularized unit design can control more flexible heat pumps
packs, with user-friendly operating system interface, easy to operate..

  1. Advanced testing methods

Adopting world-class Enthalpy potential laboratory to test heat pumps, except basic testing items, we also test heat pump
in the ambient of temperature of -30℃ to test our heat pump performance.

  1. Widely used

Heat pump is applied to hot water for household and commercial use like families, schools, hospitals, shower center,
swimming pools, etc. and industrial use like electroplating, drying, etc.

Competitive Advantage:

  1. The application of enhanced vapor injection in high temperature hot water heat pump.
  2. Using larger condenser, double efficiency of condensing, higher heating capacity.
  3. Water temperature keeps at 80℃ constantly when the ambient temperature is 5℃.
  4. Stable inside pressure, the set inside pressure keeps at 2.5mpa when hot water is 75℃,
  5. and the pressure keeps at 2.8mpa when hot water is 80℃.

95℃ hot water High temperature air source heat pump with
95℃ hot water High temperature air source heat pump with95℃ hot water High temperature air source heat pump with

Welcome to visit to our website, if you are interested in our heat pumps, please send us inquiry, we will reply you ASAP.
