30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
Specifications
Brand Name :
TRT or OEM
Model Number :
TRT-70php
Certification :
CE,CB
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
TT
Supply Ability :
2000
Delivery Time :
15-20 days
Packaging Details :
plywood
Description

Model TRT-30PHP TRT-30PHP TRT-50PHP TRT-60PHP
Metel plate Galvanized steel/Spray/Gray/White/ 304 Stainless Steel
Body size(L*W*H) 830*420*1160 830*420*1160 800*800*1070 800*800*1070
Compressor CopelandZW34KAE*1 CopelandZW61KAE*1 CopelandZW72KAE*1
Refrigerant R407C/1.8kg*1 R407C/1.8kg*1 R407C/1.9kg*1 R407C/2.4kg*1
Power Supply 220V/50Hz 380V/50Hz
Condenser Titanium tube heat exchanger
Evaporator 550-670-550*750 550-670-550*750 580-700-580*900 580-700-580*900
U-1/φ9.52/25U Pipe U-1/φ9.52/25U Pipe U-1/φ9.52/25U Pipe U-1.3/φ9.52/25U Pipe
Gas-liquid separator LF8W5A-03A*1 LF8W5A-03A*1 KFR120WLG-A*1 KFR120WLG-A*1
Four-way Valve SHF-11-45D1*1 SHF-11-45D1*1 SHF-20A-46*1 SHF-20A-46*1
Expansion Valve 2.4 2.4 3.2 3.2
AC contactor (220V-25A)*1 (220V-18A)*1 (220V-25A)*1 (220V-32A)*1
Motor/ Fan Blade 90W*1/φ490*1 90W*1/φ490*1 250W*1/φ556*1 250W*1/φ556*1
Controller Single System Single System Single System Single System
Low Pressure Switch 0.05/0.15MPa 0.05/0.15MPa 0.05/0.15MPa 0.05/0.15MPa
High Pressure Switch 2.4/3.0MPa 2.4/3.0MPa 2.4/3.0MPa 2.4/3.0MPa
Power Line 3*2.5mm2 3*2.5mm2+2*1.5mm2 3*4mm2+2*2.5mm2 3*6mm2+2*2.5mm2
Rated Heating Capacity(kW) 10 10 19 22
Input Power(kW) 1.9 1.9 3.6 4.2
Rated Current(A) 9 5 8 9
COP 5.26 5.26 5.28 5.24
Rated outlet water temperature(℃) 28 28 28 28
Max outlet water temperature(℃) 40 40 40 40
Water Flow (L/H) 2150 2150 4084 4729
Waterproof Grade IPX4 IPX4 IPX4 IPX4
Anti-electric shock Rate I I I I
Noise(dB(A)) ≤55 ≤55 ≤58 ≤58
Net Weight/ Gross Weight(kg) 90/96 90/96 125/135 135/145
Pipe size/ Inner diameter(mm) DN25 DN25 DN25 DN25
Remark: Constant water temperature 28℃, Dry bulb temperature 20℃, Wet bulb temperature15℃.

30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool

30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool

Description:

TRT Pool Heat Pump provides the maximum energy efficiency and reliability. Working efficiently, the heat pump units absorb another 6 times of free heat from the ambient environment, and transfer it to the pool water, which makes the heating process ecological and cost saving.

30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool30 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool
