Specifications
Brand Name :
TRT or OEM
Model Number :
TRT-2400-ASHP-R404A
MOQ :
1
Place of Origin :
China
Certification :
CE,CB
Price :
Negotiable
Packaging Details :
plywood
Delivery Time :
15-20 days
Payment Terms :
TT
Description
Air Cooled Screw Heat Pump
Model No. TRT-2400-ASHP-R404A
Power Supply 380V/3N/50Hz
Rated Cooling Capacity/EER A32W-7 360KW/1.5
Heat Recovery Heating Capacity 92kW
Rated Input Power/ Current 240KW/420A
Max Input Power/Current 324KW/567A
Refrigerant R404A/50000g*2
Max Discharge Pressure 3.0Mpa
Max Suction Pressure 0.8Mpa
Rated Liquid Outlet Temp -7℃
Lowest Liquid Outlet Temp -15℃
Circulation Flow 78m³/H
Anti-electric protect level / Water proof Level I/IPX4
Water Pipe Size DN80*4
Heat Revovery Water pipe size DN65*2
Water Pressure Drop ≤65kpa
Working Noise ≤78dB(A)
Working Ambient Range -7℃-43℃
Net Weight 3500Kg
Net Size 7380*2200*2410MM
Manufacturing Date Refer to Barcode
