CO2 Dual Head with Auto Feeding and Auto Control Laser Cutting /Engraving Machine (JM1610T-AT)

Product Features
Machine is equipped with auto roll conveyor system for working table, together with the precise system control adjustment, it can finish material feeding and cutting automatically, which save a lot of time and labor for material feeding, so the working efficiency is greatly enhanced. High efficiency and automation is its special advantage. This model is the best choice for the roll batch material processing.
Especially with the unique auto air driven roll conveyor system, which gives stable air pressure on the material holding, make sure the stable and continuously material feeding with 100% accuracy, it solves the problem of material waste and lose due to material feeding accuracy and material position deviation and lose problems from traditional machines with simple and easy conveyor system.

Applicable Industry
Garment, leather, cloth toys, embroidery patch cutting, Electric, mould, arts and crafts, advertising, decoration, packaging print and so on.

Applicable Materials
Fabric, leather, paper material and so on, batch roll materials and wood, organic glass, resin, acrylic, plastic, rubber, ceramic tile, crystal, bamboo and other non-metal material.

Technical parameter
Model:JM1610T-AT
Laser tube type: Hermetic and detached CO2 domestic laser tube
Cutting area: 1600mm*1000mm
Driving system: Stepping motor
Data transfer mode: Computer; USB flash disk, Internet
Maximum Memory: 128M
Laser power: 80W*2
Laser head: Dual laser head (30mm up & down adjustable)
Cooling method: Water cooling (with laser tube protection system)
Engraving speed: 0-64000mm/min
Cutting speed max: 0-36000mm/min
Support file: PLT,DST,DXF,AI,DWG,BMP,CAD,CAM,CDR and so on
Working temperature: 0-45ºC
Working humidity(RH): 5%-95%
Working table: Roll conveyor auto material feeding
Cutting power control: Fine turning possible
Power supply: 220V,50-60Hz,10AMax
