dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
Specifications
Brand Name :
topsungtech
Model Number :
DSNF-1119-24V
Certification :
CE,ROHS,UL
Place of Origin :
shenzhen china
MOQ :
50meter
Price :
US$20-25/meter
Payment Terms :
T/T, paypal, credit card, western Union
Supply Ability :
5000 meters per week
Delivery Time :
5-7 days
Packaging Details :
50meter per roll
Light Source :
LED
Item Type :
Neon Lights
LED Light Source :
SMD
Input Voltage :
24V
Lamp Power :
12W/M
Lamp Luminous Flux(lm) :
750
CRI (Ra>) :
80
Working Temperature(℃) :
-20 - 50
Working Lifetime(Hour) :
50000
Lamp Body Material :
PVC
IP rating :
IP 65
Emitting Color :
changeable
LED spacing(CM) :
1.66
Cutting unit :
10cm
Description

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

FEATURE & SPECIFICATION OF LED NEON LIGHT

Manufacturer: Topsung Lighting

Feature of Topsung Digital Neon


This Digital LED neon come with P943 IC, 10 pixel per/M,

can be controlled & addressed by DMX controller

It's waterproof IP67 and UV resistance,can be used outdoor,

with milky white diffuser and high lumen Epistar LEDs,it's super

bright and smooth emitting. 24V safer for complication.

Addressable and Programmable

Hundreds of changing modes:

  • Steady
  • Flashing
  • Fading
  • Chasing
  • Jumping
Specification of led digital neon light:
  • LED Neon Flex
  • Dimension: 14*26mm
  • Water-proof IP65
  • LED QTY:60-70leds/M
  • Lumen/Meter: 300-400lm/M (white,warm white)
  • Power: 12.5/M
  • Input voltage: 24V
360 Digital LED Neon-Flex (Topsung Lighting)
ltem NO DSNF-1119-24V
LED color RGB
Length per roll in Meters 20
Size (mm) 11x19mm Flat Surface
LED spacing (mm) 16.6
LED quantity per meter 60-70
Cutting Unit length (cm) 10
LED quantity per unit 16
Power consumption per meter MAX 12.5W
Max Loading Length (meter) 10
Voltage 24V DC
Control mode: DMX +SPI

More pictures for Flat Surface Digital Neon-Flex Strips

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/mdmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/mdmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/mdmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/mdmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

ACCESSORIES & PACKING

Accessories: (Some models no so many accessories, please contact us)
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

Packing Details:

50meter per roll per carton

Installation Notes
*A Catalog is not a substitute for user manual.
*Always follow the cut marks provided user manual
*Cut only on the cut marks provided on the fixture housing
*When applying linear solutions to a channel make certain to use an appropriate silicone adhesive between the base of the channel profile and fixture housing to eliminate stretching over time.

PAYMENT&SHIPMENT&WARRANTY

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

CERTIFICATE

Most of our Products has passed CE,ROHS, FCC, PSE, certificate

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m

FACTORY & CONTACT INFO

Shenzhen Topsung Lighting Co.,Limited with 11 years' rich experience on design/develop/export LED Products is one of the Factory of Topsung Industrial Co.,LTD. Its main procuts include: LED decoration lights (Neon, Rope, Strips,ect) & Indoor LED lights (tube, bulb, downlight, panel light,ect). Topsung Lighting cares about customer's request and deveoped new design lighting products. Welcome your inquiry!

Tel: 86-15994785513 Mail: sales (at)topsung-tech.cn Skype:topsungled

dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
Digital IC Neon-Flex RGB
  • 360 Degree Round Neon (Digital) 16mm Diameter
  • Dome Standard magic digital neon 14x26mm, 11x18mm
  • Flat /square Magic digital neon-flex 11x19mm or 17x17mm
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
1> Digital RGB Neon-Flex 24V 10pixel/M
Dome Shape:
  • 11x18mm
  • 14x26mm
Flat & Square Shape:
  • 17x17mm
  • 11x19mm
360 degree neon
  • 18mm

Hundreds of changing modes:

  • Steady
  • Flashing
  • Fading
  • Chasing
  • Jumping
  • Mono color
  • Multi Color
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m
2>Common RGB Neon-Flex
Dome Shape:
  • 11x18mm
  • 14x26mm
Flat & Square Shape:
  • 17x17mm
  • 11x19mm
360 degree neon
  • 18mm
 Tens of changing modes:
  • Steady (mono)
  • Flashing(mono)
  • Fading(multi)
dmx SPI digital RGB 11x19mm flat led neon 12v addressable neon strips 24v 10pixel/m 3> RGBW 4 Chip Neon-Flex
Dome Shape:
  • 14x26mm
Flat & Square Shape:
  • 17x17mm
 Tens of changing modes:
  • Steady (mono)
  • Flashing(mono)
  • Fading(multi)

Thanks for reading!Feel free to contact us for the update information & price!
