Specifications
Place of Origin :
China
Brand Name :
Torich
Certification :
ISO9001,ISO14001,TS16949
Model Number :
Carbon Steel,Alloy Steel
MOQ :
5 TONS
Price :
1200 USD/TON
Packaging Details :
IN BUNDLES OR WOODEN BOX
Delivery Time :
45-60 DAYS
Payment Terms :
T/T,L/C
Supply Ability :
50000 TONS PER YEAR
Grade :
A,C,D
Application :
for Boilers,Superheaters,Heat-Exchangers, Condensers
Standard :
ASTM
Description

ASTM A178 Electric resistance welded carbon steel and carbon mangaese steel boiler and superheater tubes

Size range:O.D.:6-168mm W.T.:1-15mm L: according to customer requirement

Applications: for Boilers,Superheaters,Heat-Exchangers, Condensers

Steel Grade and Chemical Compositions:
Element Grade A,
Low-Carbon Steel		 Grade C,
Medium-Carbon Steel		 Grade D,
Carbon-Manganese
Steel
Carbon 0.06-0.18 0.35 max 0.27 max
Manganese 0.27-0.63 0.80 max 1.00-1.50
Phosphorus, max 0.035 0.035 0.030
Sulfur, max 0.035 0.035 0.015
Silicon - - 0.10 min

Mechanical Properties Grade A Grade C Grade D
Tensil Streghth: min ksi[Mpa] 47[325] 47[415] 70[485]
Yield Point: min ksi[Mpa] 26[180] 37[255] 40[275]
Elongation: ≥35% ≥30% ≥30%

Tolerance for OD and WT(SA-450/SA-450M)
OD in(mm) + - WT in(mm) + -
＜1''(25.4) 0.10 0.10 ≤1.1/2''(38.1) 20% 0
1''～1.1''(25.4～38.1) 0.15 0.15 ＞1.1/2''(38.2) 22% 0
＞1.1/2''～＜2''(38.1～50.8 0.20 0.20
2''～＜2.1/2''(50.8～63.5) 0.25 0.25
2.1/2''～＜3''(63.5～76.2) 0.30 0.30
3''～＜4''(76.2～101.6) 0.38 0.38
4''～＜7.1/2''(101.6～190.5) 0.38 0.64
＞7.1/2～9''(190.5～228.6) 0.38 1.14
