Specifications
Brand Name :
Torich
Model Number :
GB, GB/T 14975, ASTM A269
Certification :
ISO9001 ISO14001 TS16949
Place of Origin :
China
MOQ :
0.5 tons
Price :
2500-5000USD/ton
Payment Terms :
L/C, T/T
Supply Ability :
50000tons per year
Delivery Time :
5-8weeks
Packaging Details :
In bundles or in woonden boxes packaging.
Material :
Stainless steel
Steel grade :
304 304L 316 316L etc
OD :
12-350mm
End :
Plain
Length :
12M Max
Production method :
Cold rolled
Description

Cold rolled Seamless Stainless Steel Tubes 304 /316

Standard: GB/T 14975, ASTM A269 / A269M, ASTM A511 / A511 M

Material: S30408 S30403 304 304L TP304 TP304L 316 316L TP316 TP316L 12Cr18Ni9, 06Cr19Ni10, 022Cr19Ni10, 06Cr19Ni10N, 06Cr19Ni9NbN, 022Cr19Ni10N, 06Cr23Ni13, 06Cr25Ni20, 015Cr20Ni18Mo6CuN, 06Cr17Ni12Mo2, 022Cr17Ni12Mo2

Cold rolled Seamless Stainless Steel Tubes 304 /316

The Tolerance of Nominal Outer Diameter and Wall Thickness Unit:mm

Cold Drawn(Roll) Steel Tube
Diamension Tolerance
Ordinary Level PA High Level PC

Nominal Outer Diameter

D

 <12.7 ±0.30 ±0.10
12.7~<38.1 ±0.30 ±0.15
38.1~<88.9 ±0.40 ±0.30
88.9~<139.7 ±0.9%D ±0.40
139.7~<203.2 ±0.80
203.2~<219.1 ±1.10
219.1~<323.9 ±1.60
≥323.9 ±0.5%D

Nominal Wall Thinckness

S

 All Wall Thickness

+12.5%S

-10%S

 ±10%S

Tolerance of Minimum Wall Thickness Unit:mm

Production Method Diamension Tolerance
Ordinary Level PA High Level PC

Hot Roll(Extrusion,Expansion)Steel Tube

W-H

 Smin<15

+27.5% Smin

0

+25% Smin

0
Smin≥15

+35% Smin

0

Cold Drawn(Roll) Steel Tube

W-C

 All Wall Thickness

+22% S

0

+20% S

0

Straightness:

The length of the steel tube should not be greater than 0.15% of the total length of the steel tube and no more than 12mm.

The bending degree of the steel pipe per meter should not be more than the following

—— WT ≤ 15mm, 1.5mm / m

—— WT > 15mm, 2.0mm / m

—— Thermal expansion pipe, 3.0mm / m

Cold rolled Seamless Stainless Steel Tubes 304 /316

Cold rolled Seamless Stainless Steel Tubes 304 /316 GB/T 14975, ASTM A269

Cold rolled Seamless Stainless Steel Tubes 304 /316 GB/T 14975, ASTM A269

Cold rolled Seamless Stainless Steel Tubes 304 /316 GB/T 14975, ASTM A269
