TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
Specifications
Brand Name :
Torich
Model Number :
DIN17175
Certification :
ISO9001 TS16949
Place of Origin :
China
MOQ :
2tons
Price :
1300-1800USD/ton
Payment Terms :
L/C, T/T
Supply Ability :
30000tons per year
Delivery Time :
5-8week days
Packaging Details :
In bundles packaging
Material :
St 52 16Mn 45# 20#
Standard :
DIN17175
Size :
60-420mm
Length :
3m 6m
Production method :
Seamless+Cold drawn
Application :
engineering and agricultural machinery
Description
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube
Standard
DIN17175, DIN2391
Material
20#, 45#, Q345
Size
OD: 5-120mm WT: 0.5-50 Length: 3-9m
Delivery Condition
+ Cc + LCc + SR + Ad + N
Test
Tensile Test, Hydraulic Test, Eddy Current Test etc
Application
Hydraulic Pipe
TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube

Mechanical Requirements
Delivery Condition
Cold Finished (Hard) (BK)
Cold Drawn and Stress-Relieved (BK+S)
Hardness HB
Parameters
T.S. Rm N/mm2
Elongation A5%
T.S. Rm N/mm2
Y.S. ReH N/mm2
Elongation A5%
20# (A106)
≥550
≥8
≥520
≥470
≥12
175
45# (CK45)
≥650
≥5
≥600
≥520
≥12
207
16Mn (ST52, E355)
≥640
≥5
≥600
≥520
≥15
190
25Mn
≥640
≥5
≥600
≥510
≥15
195
27SiMn
≥840
≥5
≥800
≥720
≥10
230

The company also committed to the production of the high quality grinding tube.

Core Technology: the automatic chroming line
The features of the automatic chroming line
1The Chroming process developed by German experts, learned from the auto industry experience, the process is advanced
2The chroming process is controlled by the computer, the stability is good
3All of the chemicals are imported, good quality and stability
