Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components
Specifications
Brand Name :
Torich
Model Number :
EN10305-1
Certification :
ISO9001 TS16947
Place of Origin :
China
MOQ :
0.5tons
Price :
2000USD/ton
Payment Terms :
L/C, T/T
Supply Ability :
5000tons per year
Delivery Time :
5-8 week days
Packaging Details :
In bundles or in wooden boxes packaging
Material :
1010，1020，1045 etc
Standard :
EN10305-1
Length :
12 m max
OD :
6-121mm
WT :
0.8-18mm
Application :
Auto Industry
Description

Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components

Production Standard:

GB/T3639,ASTM A519,DIN2391,EN10305-1,EN10305-1,Customer's special requirement will be upon discussion

Size:

O.D. 6-121mm

W.T.0.8-18mm

Material:

10,20,35,45,4130,4140,St52,45 E355 etc.

Grade and Chemical Composition ( ％ )

Grade C Mn P≤ S≤ Si Cr Mo
1008 ≤ 0.10 0.30-0.50 0.040 0.050 - - -
1010 0.08-0.13 0.30-0.60 0.040 0.050 - - -
1018 0.15-0.20 0.60-0.90 0.040 0.050 - - -
1020 0.18-0.23 0.30-0.60 0.040 0.050 - - -
1025 0.22-0.28 0.30-0.60 0.040 0.050 - - -
1026 0.22-0.28 0.60-0.90 0.040 0.050 - - -
4130 0.28-0.33 0.40-0.60 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.75-1.00 0.040 0.040 0.15-0.35 0.80-1.10

0.15-0.25

Delivery condition:

Cold drawn/hard +C

Cold drawn/soft+LC

Cold drawn and stress released:+SR

Normalizing:+N

Annealed:+A

Mechanical properties

Grade Condition Tensile Point (Mpa) Yield Point (Mpa) Elongation
1020 CW ≥ 414 ≥ 483 ≥ 5%
SR ≥ 345 ≥ 448 ≥ 10%
A ≥ 193 ≥ 331 ≥ 30%
N ≥ 234 ≥ 379 ≥ 22%
1025 CW ≥ 448 ≥ 517 ≥ 5%
SR ≥ 379 ≥ 483 ≥ 8%
A ≥ 207 ≥ 365 ≥ 25%
N ≥ 248 ≥ 379 ≥ 22%
4130 SR ≥ 586 ≥ 724 ≥ 10%
A ≥ 379 ≥ 517 ≥ 30%
N ≥ 414 ≥ 621 ≥ 20%
4140 SR ≥ 689 ≥ 855 ≥ 10%
A ≥ 414 ≥ 552 ≥ 25%
N ≥ 621 ≥ 855 ≥ 20%

Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components

QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking


100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
