3/4 1/4 1/2 3/8 1 5/8 316L Alloy 625 Alloy 825 Seamless Coiled Stainless Steel Tubing For Chemical Injection Line
3/4 1/4 1/2 3/8 1 5/8 316L Alloy 625 Alloy 825 Seamless Coiled Stainless Steel Tubing For Chemical Injection Line
3/4 1/4 1/2 3/8 1 5/8 316L Alloy 625 Alloy 825 Seamless Coiled Stainless Steel Tubing For Chemical Injection Line
3/4 1/4 1/2 3/8 1 5/8 316L Alloy 625 Alloy 825 Seamless Coiled Stainless Steel Tubing For Chemical Injection Line
Specifications
Brand Name :
Torich
Model Number :
316l
Certification :
IS09001 ISO14001 TS16949
Place of Origin :
China
MOQ :
0.5 tons
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
5000tons per year
Delivery Time :
5-8 weeks days
Packaging Details :
In plywood case
Standard :
A269 A249 etc
Material :
304，,316,2205,825,625 etc
OD :
3/4”-3”
Shape :
Round
Length :
Coil or Straight length
Application :
Chemical Injection Line
Description

3/4 1/4 1/2 3/8 1 5/8 316L Alloy 625 Alloy 825 Seamless Coiled Stainless Steel Tubing For Chemical Injection Line

Quick detail:

Standard:ASTM A213 ASTM A269 ASTM A249 ASTM 554 ASTM 270

Material :304 316 304L 316L 625 825 2507 etc

Size :3/4" 1/4 " 3/8" 1 5/8" 1"

Length: Coil ,Straight

Description:

Coiled Tubing Injector ,Stainless coiled tubing producing by standard:ASTM A213 ASTM A269 ASTM A249 ASTM 554 ASTM 270

use marterial 304 316 304L 316L 625 825 2507 etc Regular OD is 3/4" 1/4 " 3/8" 1 5/8" 1" can produce coil or straight two type.

Custom special shape coil tube is also available.

Grade 625 825 2507 etc
OD range 5-20mm
Thickness range 0.2-2mm
Length 600-3500m/coil or according to customer's requests
Surface

2B 8K bright

annealing
Test UT,HT.Gas Test,Hardness test etc

Alloy 625 Seamless Steel coiled Tubing Chemical Composition

Grade C Mn Si S Cu Fe Ni Cr
Inconel 625 0.10max 0.50 max 0.50 max 0.015max – 5.0 max 58.0 min 20.0 – 23.0

Alloy 625 Tubing Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 625 8.4 g/cm3 1350 °C (2460 °F) Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 517 42.5 %

Equivalent Grades for Inconel 625 Seamless Tubing

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 625 2.4856 N06625 NCF 625 NA 21 ХН75МБТЮ NC22DNB4M NiCr22Mo9Nb

Stainless Steel 304 Coiled Tubes/Coil Tubing
Stainless Steel 304L Coiled Tubes/Coil Tubing
Stainless Steel 304H Coiled Tubes/Coil Tubing
Stainless Steel 316 Coiled Tubes/Coil Tubing
Stainless Steel 316L Coiled Tubes/Coil Tubing
Stainless Steel 316H Coiled Tubes/Coil Tubing
Stainless Steel 317L Coiled Tubes/Coil Tubing
Stainless Steel 321 Coiled Tubes/Coil Tubing
Stainless Steel 347 Coiled Tubes/Coil Tubing
Stainless Steel 410 Coiled Tubes/Coil Tubing
Stainless Steel 904L Coiled Tubes/Coil Tubing
Stainless Steel 310S Coiled Tubes/Coil Tubing
Stainless Steel 310 Coiled Tubes/Coil Tubing
Stainless Steel 310H Coiled Tubes/Coil Tubing
Stainless Steel 316Ti Coiled Tubes/Coil Tubing
Stainless Steel 321H Coiled Tubes/Coil Tubing
Stainless Steel 347 Coiled Tubes/Coil Tubing
Stainless Steel 347H Coiled Tubes/Coil Tubing
