ASTM A513 Type 5 1026 St52.3 CDS/DOM Steel Tubes For Hydraulic Components
ASTM A513 Type 5 1026 St52.3 CDS/DOM Steel Tubes For Hydraulic Components
ASTM A513 Type 5 1026 St52.3 CDS/DOM Steel Tubes For Hydraulic Components
ASTM A513 Type 5 1026 St52.3 CDS/DOM Steel Tubes For Hydraulic Components
Specifications
Brand Name :
Torich
Model Number :
ASTM A513-5
Certification :
ISO9001,ISO14001,TS16949
Place of Origin :
China
MOQ :
10tons
Price :
1200 USD/TON
Payment Terms :
T/T,L/C
Supply Ability :
50000 TONS PER YEAR
Delivery Time :
30-60 DAYS
Packaging Details :
IN BUNDLES
Min Order :
5 tons
Shipment :
FCL, LCL workable. Bulk Vessel workable By Air, By Sea, by Courier
Thickness :
1-12.5mm
Grade :
1026 St52.3
Material :
Steel
Shape :
Round
Application :
Structure Pipe
Standard :
ASTM
Surface treatment :
Null
Alloy or not :
Non-alloy
Section shape :
Round
Production Method :
DOM
Description

ASTM A513 Type 5 1026 St52.3 CDS/DOM Steel Tubes For Hydraulic Components

TORICH is a professional seamless honed pipes manufacturer of CDS/DOM Steel Tubes ,

which is equipped with 20 lines of pipe machine.

DOM Steel Tubes, is usually produced by Drawn Over Mandrel.

DOM Steel Tubes is usually based on technical standard ASTM A519 ASTM A513 Type 5

SAE 1010, SAE1020,SA1026, SAE1045 etc or EN10305-1 DN0305-2

Applications: for Hydraulic Components

Size range: O.D.:6-320mm W.T.:1-12.5mm L:max12000mm

Steel Grade and Chemical Compositions:
Steel Grade C Mn P S Si Cr Mo
max max max max min
1008 0.10 0.5 0.035 0.035
1010 0.08-0.13 0.30-0.60 0.035 0.035
1018 0.14-0.20 0.30-0.60 0.035 0.035
1020 0.17-0.23 0.30-0.60 0.035 0.035
1026 0.22-0.28 0.60-0.90 0.035 0.035
1035 0.31-0.38 0.60-0.90 0.035 0.035
4130 0.28-0.33 0.40-0.60 0.035 0.035 0.15-0.35 0.80-1.10 0.08-0.25
4140 0.38-0.43 0.75-1.00 0.035 0.035 0.15-0.35 0.80-1.10 0.15-0.25


Feature:

DOM Steel Tube is a good candidate in applications that require high stress or

applications that need a mechanical tube with increased mechanical properties.

High accuracy for both OD(out diameter), ID(inside diameter), WT(wall thickness)

Good wall thickness uniformity

Application:

Axles,

Steering columns,

Shift levers,

Airbag inflators,

Power seat mechanisms,

Engine mounts,

Fuel rails, and injection components
