SSHM+100-160 KW 18000rpm 0.05%FS High Speed High-precision Dynamometer for Motor Test

Overview

The SSHM + dynamometer is a high-precision version of the SSHM dynamometer. Except that the torque measurement accuracy is higher than that of SSHM, the rest are the same as the SSHM dynamometer.

SSHM+ series high speed dynamometer is mainly used for testing high-speed motor, aero-engine and high-speed fluid machinery. These specimens have the characteristics of high speed.

With the help of SEELONG e-motor test system, the SSHM dynamometer can measure the power and torque of the test piece, collect the data of temperature, pressure, flow, current, voltage and other parts in real time, and complete the real-time data recording, report generation, curve generation, data calculation, etc

Applications

• Power: 100-160KW
• Torque:156Nm--254Nm
• Speed: 18.000 R / min
• Structural form: B3, B5 (additional to IEC 60034-7)
• Cooling: IC 90W (water cooling)
• Options: IC 90W and IC 06 ( air cooling)
• Protection type: IP54 (IP23 composite cooling)

Features

• 2-pole
• 1 or 2 additional air cooling
• Inverter operation (optional)
• High speed spindle bearing
• Special equipment for test bed

Benefits at a Glance

• Flexibility thanks to modular design with matched and tested components
• The highest data quality due to excellent system precision
• Dynamometers up to 18,000 rpm
• “Virtual Proving Ground“ concept based on SeeLong SLM
• Applications know-how based on the operation of its own test beds at SeeLong
• Global distribution and service network

Examples of SSHM dynamometer curves(100KW)

Application Cases

Specifications (Can be customized)

FAQ

Q:What’s the minimum order quantity for our cooperation?

A: We support small trail order of 1 pcs for stock products.

Q: How can I learn more about the products?

A: Please leave your email and we will send you your electronic sample book.

Q: What’s your payment term?

A: Normally 30% T/T deposit, pay in full before shipment.

Q:What’s the lead time for my orders?

A: Dynamometers production cycle is 6-8 weeks, sensors prodction cycle is 2-3 weeks, other products please contact with us.

Q: How do we get the overall solution of the test bench?

A: Leave us your email, our technical staff will communicate with you about the detailed plan.

Q:Can I come to visit your factory?

A: Sure, you are always welcome to have a visit.
