220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
Specifications
Brand Name :
TouchDisplays
Model Number :
1851E-IDT
Certification :
CE/FCC RoHS (UL & GS customized)
Place of Origin :
China
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
2000 units per month
Model :
1851E-IDT
Case/Bezel Color :
Black/Silvery/white/Customized colors
Screen :
18.5" Touch Screen
Optimal Resolution :
1366*768(16:9)
Warranty :
3 Years
Operating system :
Windows/ Android/Linux
Description

18.5 Inch Touch Screen POS System All In One Pos Machine Cash Register For Retail Restaurant Supermacket

18.5 inch touch screen all in one POS machine is established to withstand the continuous public use with a rugged desig and widescreen.

Its stylish, slim and fashionable outlook, also with the extendable customization with different styles of interfaces.

220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

• 18.5" wide touch screen with PCAP material

• Fanless processors with Intel branded

• Multiple peripherals optional

• High Resolution 1366*768(16:9)

• Viewing Angle from 85° to 170° degrees

HIGH QUALITY

  • Our products have certificates like CE, FCC and RoHS etc.

  • Our company has strong ability in ODM project. We have good and successful experiences of working with the famous companies overseas.

​

  • We always adhere to the guiding priciple of customer satisfaction to meet different market demands.

 220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

CPU options:

ECM3: Intel processor J1900 (Quad-core 2.0GHz/2.4GHz,Fanless)

ECM4: Intel processor i3-4010U (Dual Core 1.7GHz,Fanless)

ECM5: Intel processor i5-4200U (Dual Core 1.6GHz/2.6GHz Turbo, Fanless)

ECM6: Intel processor i7-4500U (Dual Core 1.8GHz/3GHz Turbo, Fanless)

Wide ranges intel processor from Gen 4th-7th available.

HDD:500G(1TB optional);SDD:32G(up to 128G optional);

Memory: DDR3 4G(up to 16G);

Operation System: POS Ready7 Win7Win8Win10XPWinCEVistaLinux

ECM8: Android quad-core 1.2G,Rom 1G, Flash 4G or higher

Operation System: 4.4.2 or later
220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

THE INSTALLATION

1851E offers multiple mounting options to ensure installation flexibility including: wall, arm and pole mount via standard VESA mount patterns also with the use of the desktop stand.

 220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

Support 2 line VFD and 11.6” &15.6” LCD customer display.

And more peripherals are available like MSR, Camera, RFID, Barcode Scanner and so on.

INTERFACE

220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

APPLICATION

220 Cd/M2 18.5'' Touch Screen POS System For Retail Restaurant Supermacket

SPECIFICATION

Model 1851E-IDT
Case/Bezel Color Black/Silvery/white(Customized)
Display Size 18.5"
Touch panel Projected Capacitive touch screen
Touch response time 8ms
Touchcomputors Dimensions 460.83 x 232.48 x 335.11 mm
LCD Type TFT LCD(LED backlight)
Useful Screen Area 409.8 mm x 230.4 mm
Aspect ratio 16:9
Optimal (native) Resolution 1366 x 768
LCD panel Pixel pitch 0.3 x 0.3mm
LCD panel Colors Depth 16.7M
LCD panel Brightness 250 cd/㎡
LCD panel Response Time 14 ms
Viewing Angle
(typical, from center)		 Horizontal ±80° or 160° total
Vertical ±80° or 160° total
Contrast Ratio 1000:1
output Video connector Mini D-Sub 15-Pin VGA type and HDMI type (optional)
Input interface usb 2.0*2 & usb 3.0*2 & 2*COM(3*COM optional)
1*Earphone1*Mic1*RJ45(2*RJ45 optional)
Extend interface usb2.0usb3.0comPCI-E(4G SIM card, wifi 2.4G&5G & Bluetooth module optional)M.2(for CPU J4125)
Power Supply Type Monitor input: +12V DC ±5%,5.0 A; DC Jack(2.5￠)
AC to DC power brick input: 90-240 VAC, 50/60 Hz
Power Consumption: Less than 40W
ECM
(Embed Computer Module)		 ECM3: Intel processor (J1900&J4125)
ECM4: Intel processor i3(4th -10th) or 3965U
ECM5: Intel processor i5(4th -10th)
ECM6: Intel processor i7(4th -10th)
Memory:DDR3 4G-16G Optional;DDR4 4G-16G Optional (Only for CPU J4125) ;
Storage:Msata SSD 64G-960G optional or HDD 1T-2TB optional;
ECM8: RK3288; Rom:2G; Flash:16G; Operation System: 7.1
ECM10: RK3399; Rom:4G; Flash:16G; Operation System: 9.0
Temperature Operating: 0°C to 40°C ;Storage -20°C to 60°C
Humidity (non condensing) Operating: 20%-80%; Storage: 10%-90%
Shipping Carton Dimensions 540*260*426 mm(with stand)
Weight (approx.) Actual: 6.65 kg ;Shipping: 7 kg
Warranty Monitor 3 years(Except for LCD panel 1 year)
Backlight lamp life: typical15,000 hours to half brightness
Agency Approvals CE/FCC/RoHS (UL & GS & CB & TUV customized)
Mounting Options 75 mm and 100mm VESA mount
