15 / 17 / 19 Inch, Embedded Touch Capacitor, Industrial Wall Mounted Tablet PC
Industrial control all-in-one machine, including embedded industrial touch all-in-one machine, wall mounted industrial touch integrated machine and other styles. Independent research and development of the whole machine, industrial Android tablet computer, create a new interactive experience.
1. Industrial touch integrated machine: resistance touch, capacitance touch.
2. The difference between capacitance screen and capacitance screen: the capacitance screen can be finger or special touch pen, ten touch, and the response speed is fast. Resistance screen is through pressure induction, single touch, press sense, short life.
3. The six technical advantages of industrial protection are: high dust environment, electromagnetic interference environment, high and low temperature environment, waterproof splash environment, static environment and oil smoke environment.
4. Starting from the appearance, loyal to performance: the frame adopts chrome plating process, and the fashionable arc black edge makes the overall metal texture better.
5. Full enclosed military class, all aluminum shell, dust-proof design: use strong and tough to challenge the harsh working environment, and the fully closed design is more effective in dust prevention, oil prevention and water proofing.
6. The whole machine is more resistant to high and low temperature: the product can adapt to temperature between -10 ℃ and 60 ℃ through controllable high temperature test, even in the harsh environment.
7. Sensitive translation, timely response: product response time is fast and efficient, which makes people feel the trigger.
8. Compatible with a variety of operating systems: excellent compatibility, compatible with running a variety of systems, win7/win8/win10, like a tablet, easy to operate, intelligent and fast.
9. Many installation methods, use more options: folding bracket, triangle support, wall mount bracket.
10. Rich interface, meet a variety of high requirements: Standard Interface USB, com, VGA, HDMI, LAN, etc.
Brand:LIQUISE Screen specifications: 15 inches Screen ratio: 4:3 Resolution: 1024x 768 Backlight type: LED Motherboard: J1800/J1900 industrial control motherboard | Memory: 2G/4G/8G (upgradeable) Interface: VGA x 1HDMIx 1USBx4L AN Power connector x 1 Network card: Built-in Gigabit network card Graphics: Integrated HD
|
Common system: win7/win10/Android Normal power: ≤40W Working temperature: -10C~+60C Environmental humidity: 20%~70% Product certification: CE, FCC, CCC Applicable industries: Industry, Commerce
| Touch screen: Resistive/Capacitive Response time: 5ms Display brightness: 350cd/m2 Contrast ratio: 1000:1 Color depth: 16.7M CPU: Celeron dual-core 2.41GHz/quad-core 1.99GHz
|
Power supply: External power supply 12V Special structure: Fanless dustproof structure Aluminum alloy cooling back cover Can be installed and built-in: Wireless wifi, 4G, Bluetooth(optional) Viewable size: 304mm x 228mm Shell size: 378mm x 297mm
| Bracket hole: 75mm x 75mm Appearance material: Metal cold rolled sheet Bracket: Wall Hanger / Die-casting desktop bracket (optional) |
Capacitor size Shell width(mm)
Shell heigh(mm)
Thickness(mm)
Screen width(mm)
Screen heigh(mm)
Screen Resolution (mm) Wall hole position (mm) Screen width:height
| 8.4inches 236
190
51.5
170.4
127.8
800*600
100*100
4:3
| 10.4 inches 283
225.2
56.2
213.1
160.3
1024*768
100*100
4:3
| 12.1 inches 317
258
56.2
246
184.5
1024*768
100*100
4:3
| 15 inches 378
297
56.2
304
228
1024*768
100*100
4:3
| 17 inches 413
342
56.2
338.92
271.34
1280*1024
100*100
4:3
| 19 inches 454
375.5
62.7
377.3
302.1
1280*1024
100*100
4:3
| 22 inches 559
349.3
65.5
477.6
261.1
1920*1080
100*100
16:9
|
