15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance
15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance
15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance
15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance
Specifications
Brand Name :
GreenTouch
Model Number :
GT-TC-1505A
Certification :
CE, FCC, ROHS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, MoneyGram
Supply Ability :
10,000pcs per month
Delivery Time :
3-7 working days after received your payment
Packaging Details :
carton
Resolution :
1024x768
Display type :
TFT LCD/LED panel
Case/ frame color :
Black / Silver color
Display Colors :
16.7M
Response time (standard) :
12msec
Contrast ratio (standard) :
700: 1(Typ.)
Description

15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance

Features:

• Optional Motherboard Configuration inlcudes:
Intel NM70 chipset with: Celeron C1037 @1.8GHz
Intel Bay Trail-d chipset with: Celeron J1900 @1.99GHz

Intel Haswell-u chipset with

Intel Core I3-4005U @1.7GHz

Intel Core I3-4025U @1.9GHz

Intel Core I5-4210U @1.6GHz

Intel Core I5-4300U @1.9GHz

Intel Core I7-4500U @1.8GHz

Intel Core I7-4600U @2.1GHz

• Optional touch technologies include:
four-wire resistive
five-wire resistive

Surface accoustic wave

Infrared
Projected capacitive

• Compact and easy to integrate with mounting from sides or top and bottom; also a VESA mount option

• Worldwide agency approvals

• One year standard warranty

Product image:

15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance

Specification :

Case/ frame color

Black / Silver color

Machine dimensions

Monitor(329.5mm(W) x256.5 mm(H),Thickness: 55 mm)

Resistive version(329.5mm(W) x256.5 mm(H),Thickness: 58 mm)

Infrared version (342mm(W)x266mm(H), Thickness: 63 mm)

Projected Capacitive (358.5 mm(W) x282.5 mm(H),Thickness: 58 mm)

Display type

15’’Diagonal,Ratio4:3,Active matrix TFT LCD, LED backlight

Resolution(pixel)

1024 x 768@60Hz

Active Area Dimensions

304mm(H) x 228mm(V)

Display Colors

16.7M

Brightness (Standard)

4-wire resistive / 5-wire resistive: 400 nits(Typ.); Projected Capacitive / Infrared:450nits(Typ.)

Response time (standard)

12msec

View Angle(from center)

Horizontal (left / right): ± 80° or total 160° Vertical (up / down): ± 70° or a total of 140°

Contrast ratio (standard)

700: 1(Typ.)

Touch Technology

4-wire,5-wire,projected capacitive,Infrared

Motherboard

Intel NM70 chipset with: Celeron C1037@1.8GHz
Intel Bay Trail-d chipset with: Celeron J1900@1.99GHz Intel Haswell-u chipset with: Intel Core I3-4005U @1.7GHz Intel Core I3-4025U @1.9GHz Intel Core I5-4210U @1.6GHz Intel Core I5-4300U @1.9GHz Intel Core I7-4500U @1.8GHz Intel Core I7-4600U @2.1GHz

Graphics

Onboard Intel HD graphics

Sound Card

Onboard Realtek ALC662HD audio decoding

RAM

Optional DDR3 1600 2GB,4GB,8GB

SSD

32G,64G,128G

HDD

Another 2.5’’HDD can be added

Wifi

Built-in 802.11b / g / n wireless, external two 3DB omnidirectional antenna

Speakers

Built-in 2*3W speakers

Extra Video output

1*VGA;1*HDMI

USB interface

2*USB2.0,2*USB3.0(USB2.0 for C1037)

Network card

1 road onboard Realtek 8111e Gigabit

Audio Interface

1*3.5mm Audio input;1*3.5mm Audio output

RS232 interface

4*RS232(standard)interfaces

Power

External DC, input voltage DC: 12V; INPUT POWER CONNECTOR SPECIFICATIONS (for all in one PC) - Type: DC cartridge receptacle; Cartridge ID: 5.5 mm (± 0.3 mm); Needle OD: 2.0 mm (+0.0 -0.1 mm); Cartridge depth: 8.0 mm (± 0.3 mm);

Power consumption (standard)

Depend on Motherboard and the minimum is 25W

Supported OS

Support Windows OS(J1900 support Windows7 or up only);Linux;Android x86

Temperature

Operating: 0 ° C to 60 ° C; Storage: -20 ° C to 60 °C

Humidity

Operating: 20% to 80% (non-condensing); Storage: 5% to 95% (non-condensing)

Warranty

1 year

Weight (approx.)

Net weight: 3.5 kg(Typ.); Shipping: (5 kg (reference)

Mounting options

100mm or 75mm VESA mounting,open bracket mounting

Agency Approvals

UL,cUL (Recognized), FCC, CE,CCC, China RoHS CQC

Ordering Information :

Model

Part Number

Technology

Surface Treatment

Availability

1505A

GT-OC-1505A-PC

Clear

Worldwide

GT-TC-1505A-4W-PC

4-wire resistive

Antiglare

Worldwide

GT-TC-1505A-5W-PC

5-wire resistive

Antiglare

Worldwide

GT-TC-1505A-CTW-PC

W-series PCAP

Clear

Worldwide

GT-TC-1505A-IRB-PC

B-series Infrared

Clear

Worldwide

GT-TC-1505A-IRK-PC

K-series Infrared

Clear

Worldwide

Applications :

• Information Kiosk
• Game and Entertainment

• Industrial Automation
• Self-checking service

15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance

Shipping & Payment:

15 Inch Open Frame Wall Mounted Touch Screen Computer 5A Series High Performance

1505A 15 "Open touch all-in-one PC

GreenTouch's 1505A 15 "Open frame touch all-in-One PC is the integrated touch solution designed for

automatic information systems, gaming and entertainment, as well as industrial Automation and control.

1505A open frame touch all-in-one PC is made based on the idea "designed for simple and convenience"

and with the proven GreenTouch professionalism and reliability. The precise small frame design makes

it easier for customers to install them product in the cabinet. Designed and built by GreenTouch, the

model has a long life cycle and can offer long-term demands.

1505A 15 "open frame touch all in one PC is with versatile and powerful function and modular design.

On configuration options, customers can choose INTEL C1037 program for their low requirement and

also recommend INTELJ1900 which is ultra-low power consumption and cost-effective; For customers

with high requirement, the optional can be hasswell-U chipset with more powerful I3 / I5 / I7-U which is

board-built with Intel HD graphics and audio decoding and the different capacity of memory is available,

built-in MSTAT SSD. The second 2.5-inch hard drive can enhance storage capacity; dual antenna WIFI,

built-in speaker, 12V low voltage power supply.

About GreenTouch:

Shenzhen GreenTouch Technology Co., Ltd. is a professional manufacturer of product.Our company specializes

in R&D, manufacture and marketing of high-grade touch screen and value-added touch machine. Our company

has our own brand—GreenTouch and provides customers with touch products including SAW touch screen, IR

touch screen, four-wire touch screen, five-wire touch screen,various touch screen monitors and touch all in one

PC TV. GreenTouch has automatic production lines and the sealed dust-free workshops and has been certified

to ISO9001Quality Management System and ISO14001 Environmental Management System. The products are

inspected in strict accordance with the quality management system. Quality management becomes an essential

part of operation.Our products have been certified to CE, FCC, ETL, ROHS andUL. The objective of GreenTouch

is to become the most reliable supplier oftouch screen, high value-added and special touch products and touch

solutions in the world.
