16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor
16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor
16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor
16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor
Specifications
Brand Name :
GreenTouch
Model Number :
GT-4W-8.0A-1
Certification :
CE, FCC, ROHS
Place of Origin :
China
MOQ :
50
Payment Terms :
MoneyGram, T/T,
Supply Ability :
10,000pcs per month
Delivery Time :
3-7 working days after received your payment
Packaging Details :
carton
Resolution :
4096x4096
Working environment :
Under sunlight, indoor and outdoor
Response time :
Less than 10ms
Screen Ratio :
16:9
Position accuracy :
1.15~2.5mm
Linearity :
≤1.5%
Description

16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor

Model Information:

Model number Outline(mm) Viewing Area(mm) Active Area(mm) Thickness(mm) FPC location
GT-4W-8.0A-1 168.6 x 130.9 163.6x 123.1 163x 122.5 1.4mm Long side

Product Specification

Interface Type: USB or RS232
Resolution 4096x4096
Screen Ratio 16:9
Material ITO Glass + ITO Film
Certificates CE, FCC, RoHS
Input method Finger or touch pen
Position accuracy 1.15~2.5mm
Operating Voltage DC ≤ 10V
Operating current 5~25mA
Response time Less than 10ms
Touch action force 20~100g
Operating temperature -10°C~60°C
Storage temperature -20°C~70°C
Surface hardness 3H
Working environment Under sunlight, indoor and outdoor
Transparency ≥75%
Isolation resistance ≥20MΩ DC 25V
X.Y resistance 100Ω~1000Ω according to the size
Linearity ≤1.5%
The number of hits ≥1,000,000/point
Warranty 1 year
Support Systems Windows 2000/Windows XP/Win 7/ Win 8/Windows NT/Linux/Mac

16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor


Applications:

4 Wire Resistive touchscreen is an outstanding high quality product, suitable for low cost solution. Suitable
for GPS, medical, Light industrial ,Pos,Portable sport devices, Access control terminals, Portable medical
devices, LCD and LED touch monitors,All-In-One ,Home appliances and other fields.
16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor

Packing and shipping:

16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor

Certificate:

16 / 9 CE 8 Inch Resistive Touch Screen Panel With USB Controller Touch Monitor
