Specifications
Brand Name :
WCH Cable
Model Number :
UL21311
Certification :
UL, Cul, AWM
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.1086 per meter
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5,000,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
152.5 meters or 305 meters per reel, optional
Approval Style :
UL21311
Conductor Material :
Highly Pure Copper Wires
Rated Temperature :
80C Degrees
Insulation Material :
LSZH complying material
Rated Voltage :
300V
Eco Standard :
Halogen Free Complied
Description

UL21311 LSZH Flat Ribbon Cable Top Coated Copper Conductors 80C 300V

Style Number: UL21311;

Insulation material: LSZH complying material;

Rated: 80C degrees, 300V;

Conductor Tyle: Top coated over stranded copper wires conductors;

Applied standard: UL758, UL1581;

Application: internal wiring of electronic devices.

Style Number Conductor Gauge Conductor Strands Pitch Distance Pin Quantity Insulation Thickness Overall Diameter Conductor Resistance
AWG No/mm mm Pin mm mm Ω/KM
UL21311 24 7/0.203 1.40 2 0.38 1.40x2.90 94.20
24 7/0.203 1.40 3 0.38 1.40x4.40 94.20
24 7/0.203 1.40 4 0.38 1.40x5.90 94.20
24 7/0.203 1.40 5 0.38 1.40x7.40 94.20
24 7/0.203 1.40 6 0.38 1.40x8.90 94.20
24 7/0.203 1.40 7 0.38 1.40x10.40 94.20
24 7/0.203 1.40 8 0.38 1.40x11.90 94.20
24 7/0.203 1.40 9 0.38 1.40x13.40 94.20
24 7/0.203 1.40 10 0.38 1.40x14.90 94.20
24 7/0.203 1.40 11 0.38 1.40x16.40 94.20
24 7/0.203 1.40 12 0.38 1.40x17.90 94.20
24 7/0.203 1.50 2 0.38 1.40x3.20 94.20
24 7/0.203 1.50 3 0.38 1.40x4.60 94.20
24 7/0.203 1.50 4 0.38 1.40x6.20 94.20
24 7/0.203 1.50 5 0.38 1.40x7.60 94.20
24 7/0.203 1.50 6 0.38 1.40x9.20 94.20
24 7/0.203 1.50 7 0.38 1.40x10.60 94.20
24 7/0.203 1.50 8 0.38 1.40x12.10 94.20
24 7/0.203 1.50 9 0.38 1.40x13.60 94.20
24 7/0.203 1.50 10 0.38 1.40x15.10 94.20
24 7/0.203 1.50 11 0.38 1.40x16.60 94.20
24 7/0.203 1.50 12 0.38 1.40x18.10 94.20
24 7/0.203 2.54 2 0.38 1.40x5.08 94.20
24 7/0.203 2.54 3 0.38 1.40x7.62 94.20
24 7/0.203 2.54 4 0.38 1.40x10.16 94.20
24 7/0.203 2.54 5 0.38 1.40x12.70 94.20
24 7/0.203 2.54 6 0.38 1.40x15.24 94.20
24 7/0.203 2.54 7 0.38 1.40x17.78 94.20
24 7/0.203 2.54 8 0.38 1.40x20.32 94.20
24 7/0.203 2.54 9 0.38 1.40x22.86 94.20
24 7/0.203 2.54 10 0.38 1.40x25.40 94.20
24 7/0.203 2.54 11 0.38 1.40x27.94 94.20
24 7/0.203 2.54 12 0.38 1.40x30.48 94.20
24 7/0.203 2.54 13 0.38 1.40x33.02 94.20
24 7/0.203 2.54 14 0.38 1.40x35.56 94.20
24 7/0.203 2.54 15 0.38 1.40x38.10 94.20
24 7/0.203 2.54 16 0.38 1.40x40.64 94.20
24 7/0.203 2.54 17 0.38 1.40x43.18 94.20
