1000V PUR Curly Cable UL20234 26AWG 6C OD5.5mm VW-1 Glossy Black L=350mm
1000V PUR Curly Cable UL20234 26AWG 6C OD5.5mm VW-1 Glossy Black L=350mm
Specifications
Brand Name :
WCH Cable
Model Number :
WCH-260606350
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
100 PCS
Price :
USD0.3212
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000pcs per month
Delivery Time :
9 days for ready goods
Packaging Details :
200pcs per carton
Rated Voltage :
1000V
Jacket Material :
PUR
Product Name :
Curly Cable
UL Style :
20234
Curly Segment :
350mm
Colour :
Glossy Black
Description

1000V PUR Curly Cable UL20234 26AWG 6C OD5.5mm VW-1 Glossy Black L=350mm

Spiral Cable
Construction		 Spiral Length (unexpanded) (mm) 350
Straight Ends (mm/mm) 1500/650
Extension Ratio 　 1 : 3.5
Spiral Outer Ø (mm) 20.00
Tail Angle 　 90 degree
End Treatment 　 Cut Flat
Electrical
Capability		 Working Voltage (V) 1000
Temp Range (°C) -40 to +80
Test Voltage (V) 2000/3000
Nominal Voltage (V) 1000
Conductor Resistance (Ω/KM 20°C) 150
Insulation Resistance (MΩ/KM 20°C) 10
Standard
& Use		 UL Marking 　 Per UL20234
CUL Standard 　 I/II A
Flammability 　 VW-1
Raw Cable
Construction		 Conductor Size (AWG) 26
Insulation Material 　 PVC (RoHS)
Insulation Diameter (mm) 1.00
Conductor Quantity 　 6 Cores
Assembly 　 Stranded in layers
Overall Diameter (mm) 5.50
Jacket Material 　 PUR (RoHS)
Surface Effect 　 Glossy Black
