XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors
Specifications
Brand Name :
WCH Cable
Model Number :
UL21016 AWG26 PH0.90 GRY+BLK
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.2086 per meter
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5,000,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
152.5 meters or 305 meters per reel, optional
UL Style :
21016
Gauge :
26AWG
Pitch Distance :
0.90mm
Pin Quantity :
64 Pins
Colour :
Gray Color With Black Marking
Conductor Type :
Tinned Stranded Copper Wire
Description

XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors

XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors

WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly

Conductor Specification (AWG) 28
Section Area (mm²) 0.089
Material 　 Tinned Stranded Copper Wire
Configuration (mm) TS7/0.127±0.007
Insulation Pitch Distance (mm) 0.90
Ave Thickness (mm) 0.23
Min Thickness (mm) 0.20
Over Diameter (mm) 0.90±0.10
Material 　 XLPE (RoHS)
Colour 　 8002K Gray
Electrical
Capability		 Rated Temperature (℃) 105
Rated Voltage (V) 300
Conductor Resistance (Ω/KM 20℃) 150.0
Insulation Resistance (MΩ/KM 20℃) 100
Flammability UL Fire Resistant 　 --
CSA Fire Resistant 　 FT2
Approval UL Style Number 　 21016
CSA Standard 　 I / A
Based Standard 　 Lead Free
Environmental Standard 　 RoHS & Reach Compliant

XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors

XLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper ConductorsXLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper ConductorsXLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper ConductorsXLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper ConductorsXLPE Flat Ribbon Cable UL21016 #28AWG 64Pins 0.90mm Pitch Tinned Stranded Copper Conductors

Tag: UL21016, UL21016 XLPE cable, XLPE Flat Ribbon Cable
