Specifications
Brand Name :
WCH Cable
Model Number :
UL20844
Certification :
UL, Cul, AWM
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD0.10 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
305 meters per spool / reel
Conductor :
Pure Copper Conductor
Insulation :
AWM Material
Rated Voltage :
30V (Low Voltage)
Jacket Material :
TPE Thermoplastic Elastomer
Feature :
Torsion Resistant
Style Number1 :
UL20844, UL20255
Application :
Automotive
Style Number2 :
UL20256, UL20330
Description

Approval style number: UL20844

Rated temperature and voltage: 80 deg C, 30 Vac, Cable flame.

Conductor: pure copper wire conductor.

Insulation material: PVC, PP, HDPE, LDPE, SR-PVC, XL-PE, XL-PVC, TPE, FRPE.

Jacket material: Extruded TPE.

Applied standard: Appliance Wiring Material UL 758.

Application: External interconnection of electronic equipment.

Origin: Dongguan, China

Equivalent approval style numbers of 30V Low Voltage Torsion Resistant Automotive TPE Cable:

Approval Style Temperature Voltage Material Brand
UL 20844 80 30 Thermoplastic Elastomer / TPE WCH Cable
UL 20255 90 30 Thermoplastic Elastomer / TPE WCH Cable
UL 20256 105 30 Thermoplastic Elastomer / TPE WCH Cable
UL 20330 105 30 Thermoplastic Elastomer / TPE WCH Cable


Parameters of 30V Low Voltage Torsion Resistant Automotive TPE Cable:

Approval Style Number Cores Conductor Insulation
Thickness		 Nom.Dia Shield Coverage Jacket Thickness Overall
Diameter		 Conductor
Resistance
AWG No/mm mm mm % mm mm Ω/KM
UL20844 2C 30 7/0.100 0.23 0.80 >=65 0.76 3.80 381.00
28 7/0.127 0.23 0.90 >=65 0.76 4.00 239.00
26 7/0.16 0.23 1.00 >=65 0.76 4.10 150.00
24 11/0.16 0.23 1.10 >=65 0.76 4.20 94.20
22 17/0.16 0.23 1.30 >=65 0.76 4.60 59.40
20 21/0.178 0.23 1.50 >=65 0.76 5.00 36.70
18 34/0.178 0.23 1.80 >=65 0.76 5.60 23.20
16 26/0.25 0.23 2.00 >=65 0.76 7.80 14.60
UL20844 3C 30 7/0.100 0.23 0.80 >=65 0.76 4.00 381.00
28 7/0.127 0.23 0.90 >=65 0.76 4.20 239.00
26 7/0.16 0.23 1.00 >=65 0.76 4.40 150.00
24 11/0.16 0.23 1.10 >=65 0.76 4.60 94.20
22 17/0.16 0.23 1.30 >=65 0.76 5.20 59.40
20 21/0.178 0.23 1.50 >=65 0.76 5.50 36.70
18 34/0.178 0.23 1.80 >=65 0.76 6.10 23.20
UL20844 4C 30 7/0.100 0.23 0.80 >=65 0.76 4.20 381.00
28 7/0.127 0.23 0.90 >=65 0.76 4.40 239.00
26 7/0.16 0.23 1.00 >=65 0.76 4.70 150.00
24 11/0.16 0.23 1.10 >=65 0.76 5.10 94.20
22 17/0.16 0.23 1.30 >=65 0.76 5.40 59.40
20 21/0.178 0.23 1.50 >=65 0.76 5.90 36.70
UL20844 5C 30 7/0.100 0.23 0.80 >=65 0.76 4.40 381.00
28 7/0.127 0.23 0.90 >=65 0.76 4.60 239.00
26 7/0.16 0.23 1.00 >=65 0.76 4.70 150.00
24 11/0.16 0.23 1.10 >=65 0.76 5.10 94.20
22 17/0.16 0.23 1.30 >=65 0.76 5.70 59.40
UL20844 6C 30 7/0.100 0.23 0.80 >=65 0.76 4.60 381.00
28 7/0.127 0.23 0.90 >=65 0.76 5.00 239.00
26 7/0.16 0.23 1.00 >=65 0.76 5.40 150.00
24 11/0.16 0.23 1.10 >=65 0.76 5.70 94.20
