UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
Specifications
Brand Name :
WCH Cable
Model Number :
WCH-UL3619
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
610 meters
Price :
USD 0.03 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4000000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
610 meters per reel
Feature :
Electrical Hook Up
Wire Type :
XLPE
Rated Temperature :
105℃
Rated Voltage :
150V
UL Style :
UL3619
RoHS Compliant :
Yes
Description

UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V

Tinned, annealed, stranded or solid copper conductor.

XL-PE insulation.

Rated temperature: 80/105℃. Rated voltage: 150volts.

Uniform thickness of wire to ensure easy stripping and cutting.

UL VW-1 vertical flame test verified.

Top coated conductor is available.

Application: For general purpose internal wiring of electronic or electrical equipment.

UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V

UL Style & CSA Type Conductor Insulation
Thickness		 Overall
Diameter		 Standard Put-up Conductor
Resistance
AWG No/mm mm mm Feet/reel Meter/reel Ω/KM
UL3619
(Stranded)		 30 7/0.100 0.25 0.80 2000 610 381.00
28 7/0.127 0.25 0.90 2000 610 239.00
26 7/0.160 0.25 1.00 2000 610 150.00
24 11/0.60 0.25 1.10 2000 610 94.20
22 17/0.160 0.25 1.30 2000 610 59.40
20 21/0.178 0.25 1.50 2000 610 36.70
UL3619
(Top-coated)		 28 7/0.127 0.25 0.90 2000 610 239.00
26 7/0.160 0.25 1.00 2000 610 150.00
24 7/0.200 0.25 1.10 2000 610 94.20
22 7/0.250 0.25 1.30 2000 610 59.40
UL3619
(Solid)		 28 1/0.320 0.25 0.90 2000 610 239.00
26 1/0.404 0.25 1.00 2000 610 150.00
24 1/0.511 0.25 1.10 2000 610 94.20
22 1/0.643 0.25 1.30 2000 610 59.40
20 1/0.813 0.25 1.50 2000 610 36.70


UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V

UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V

UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V

UL3619 XLPE Insulated Electrical Hook Up Copper Wire Rated 105℃ 150V
