UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
Specifications
Brand Name :
WCH Cable
Model Number :
WCH-UL3135
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
610 meters
Price :
USD 0.05 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4000000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
610 meters per reel
UL Style :
UL3135
Feature :
High Temperature Resistant
Gauge :
26AWG - 12AWG
Wire Type :
Silicone Rubber
Rated Temperature :
200℃
Rated Voltage :
600V
Description

UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V

High purity of copper wire conductors
Conductor size: 26AWG ~ 12AWG
Tinned annealed or bare, stranded or solid copper conductor.
Silicone rubber insulation.
Rated temperature 200℃.
Rated voltage 600V.
Uniform wall thickness of insulation for easy stripping and cutting.
UL VW-1 and CUL FT1 flame test verified.
Top coated conductor is available.


UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V

UL Style& Cul TypeConductorInsulation
Thickness		Overall
Diameter		Standard Put-upConductor
Resistance
AWGNo/mmmmmmFeet/reelMeter/reelΩ/KM
UL3135
CUL AWM I A
(Stranded)		267/0.160.762.042000610150
247/0.200.762.17200061094.2
2411/0.160.762.17200061094.2
227/0.250.762.33200061059.4
2217/0.160.762.33200061059.4
207/0.310.762.48200061036.70
2021/0.1780.762.48200061036.70
187/0.390.762.75200061023.20
1834/0.1780.762.75200061023.20
167/0.50.763.09100030514.60
1626/0.250.763.09100030514.60
1437/0.260.763.4410003058.96
1441/0.250.763.4410003058.96
1245/0.320.764.0010003055.64
1265/0.250.764.0010003055.64
UL3135
CUL AWM I A
(Solid)		261/0.400.762.042000610140
241/0.510.762.17200061087.5
221/0.640.762.33200061055.0
201/0.810.762.48200061034.6
181/1.020.762.75200061021.8
161/1.290.763.09100030513.7
141/1.630.763.4410003058.62
121/2.050.764.0010003055.43


UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V

UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V

UL3135 High Temperature Resistant Electronic Silicone Rubber Wire Rated 200℃ 600V
