Specifications
Brand Name :
WCH Cable
Model Number :
WCH-UL3265
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
610 meters
Price :
USD 0.05 per meter
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
400000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
610 meters per reel
Feature :
High temperature resistant
Wire Type :
XLPE
Rated Temperature :
125℃
Rated Voltage :
150V
UL Style :
UL3265
Irradiated :
Yes
Description

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V

Tinned, annealed, stranded or solid copper conductor.

XL-PE insulation.

Rated temperature: 125℃. Rated voltage: 150volts.

Uniform thickness of wire to ensure easy stripping and cutting.

UL VW-1 vertical flame test verified.

Top coated conductor is available.

Application: For general purpose internal wiring of electronic or electrical equipment.

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V

UL Style Conductor Insulation
Thickness		 Overall
Diameter		 Stand Put-up Conductor
Resistance
AWG No/mm mm mm Ft/coil M/Coil Ω/KM
UL3265

(Stranded)		 30 7/0.10 0.25 1.30 2000 610 150.00
28 7/0.127 0.25 2.10 2000 610 94.20
26 7/0.16 0.25 2.20 2000 610 150.00
24 11/0.16 0.25 2.30 2000 610 94.20
22 17/0.16 0.25 2.40 2000 610 59.40
20 21/0.178 0.25 2.60 2000 610 36.70
18 34/0.178 0.25 2.80 2000 610 23.20
16 26/0.25 0.25 3.20 1000 305 14.60
14 41/0.25 0.25 3.50 1000 305 8.96
12 65/0.25 0.25 4.00 1000 305 5.64
10 105/0.25 0.25 4.70 1000 305 3.55

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V

UL3265 High Temperature Resistant Crosslinked XLPE Wire Rated 125℃ 150V
