Specifications
Brand Name :
WCH Cable
Model Number :
UL21140
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.15 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
305 meters per spool
Sheath Material :
Thermoplastic Polyurethane TPU
Voltage Rated :
1000V
Temperature Rated :
80C
Feature :
Oil Resistant
Standard :
UL758
Style Number1 :
UL20234, UL20940
Green Standard :
RoHS & Reach Compliant
Style Number2 :
UL21140, UL21223
Description

UL Cable Style: Multiple-conductor cable using non-integral jacket

Jacket Type: PUR, TPU.

Standard: Appliance Wiring Material UL758.

Rated: 60 deg C, 600, 1000 Vac, Cable flame.

Application: External interconnection of electronic equipment.

Approval UL Style Number of 1000V High Voltage TPU Cable:

Style# Temperature Voltage Sheath Material Type Brand
UL20234 80 600/1000 Thermoplastic Polyurethane PU / PUR / TPU WCH Cable
UL20940 80 600/1000 Thermoplastic Polyurethane PU / PUR / TPU WCH Cable
UL21140 60 600/1000 Thermoplastic Polyurethane PU / PUR / TPU WCH Cable
UL21223 80 600/1000 Thermoplastic Polyurethane PU / PUR / TPU WCH Cable

1000V TPU Cable Parameters:

Approval Style Number Cores Conductor Insulation
Thickness		 Nom.Dia Shield Coverage Jacket Thickness Overall
Dimeter		 Conductor
Resistance
AWG No/mm mm mm % mm mm Ω/KM
UL21140 2C 30 7/0.100 0.76 1.90 >=65 1.15 6.70 381.00
28 7/0.127 0.76 2.00 >=65 1.15 7.00 239.00
26 7/0.16 0.76 2.10 >=65 1.15 7.10 150.00
24 11/0.16 0.76 2.20 >=65 1.15 7.30 94.20
22 17/0.16 0.76 2.40 >=65 1.15 7.70 59.40
20 21/0.178 0.76 2.50 >=65 1.15 8.10 36.70
18 34/0.178 0.76 2.80 >=65 1.15 8.70 23.20
16 26/0.25 0.76 3.10 >=65 1.15 10.90 14.60
UL21140 3C 30 7/0.100 0.76 1.90 >=65 1.15 8.60 381.00
28 7/0.127 0.76 2.00 >=65 1.15 8.80 239.00
26 7/0.16 0.76 2.10 >=65 1.15 9.00 150.00
24 11/0.16 0.76 2.20 >=65 1.15 9.20 94.20
22 17/0.16 0.76 2.40 >=65 1.15 9.60 59.40
20 21/0.178 0.76 2.50 >=65 1.15 10.10 36.70
18 34/0.178 0.76 2.80 >=65 1.15 10.70 23.20
UL21140 4C 30 7/0.100 0.76 1.90 >=65 1.15 8.80 381.00
28 7/0.127 0.76 2.00 >=65 1.15 9.00 239.00
26 7/0.16 0.76 2.10 >=65 1.15 9.30 150.00
24 11/0.16 0.76 2.20 >=65 1.15 9.60 94.20
22 17/0.16 0.76 2.40 >=65 1.15 10.00 59.40
20 21/0.178 0.76 2.50 >=65 1.15 10.50 36.70
UL21140 5C 30 7/0.100 0.76 1.90 >=65 1.15 9.10 381.00
28 7/0.127 0.76 2.00 >=65 1.15 9.40 239.00
26 7/0.16 0.76 2.10 >=65 1.15 9.50 150.00
24 11/0.16 0.76 2.20 >=65 1.15 9.90 94.20
22 17/0.16 0.76 2.40 >=65 1.15 10.60 59.40
UL21140 6C 30 7/0.100 0.76 1.90 >=65 1.15 9.50 381.00
28 7/0.127 0.76 2.00 >=65 1.15 9.80 239.00
26 7/0.16 0.76 2.10 >=65 1.15 10.10 150.00
24 11/0.16 0.76 2.20 >=65 1.15 10.40 94.20
