UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V
Specifications
Brand Name :
WCH Cable
Model Number :
UL20694
Certification :
UL, Cul, AWM
Place of Origin :
Dongguan, China
MOQ :
200 pcs
Price :
USD0.348 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000pcs per week
Delivery Time :
9 days for ready goods
Packaging Details :
200 pcs per box
Conductor :
High purity copper wire
Rated Temperature :
80 Deg C
Insulation :
AWM Appliant Material
Rated Voltage :
450V, or determined per request.
Jacket Material :
Thermoplastic Polyurethane TPU
Standard Reference :
UL758, UL20694
Description

Feature of UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V

Conductor: High purity copper wire, tinned or bare, stranded or solid.
Insulation: Quality materials complying with AWM standard.
Screen Shield: Foil, spiral shield, copper braiding, optional.
Jacket: Polyurethane PUR
Standard: Appliance Wiring Material UL758.
Rated Temperature: 80 deg C.
Rated Voltage: 450V, or determined per request.
Flammability: UL VW-1 passed.
Uniform insulation thickness for smooth stripping.
Other approvals: Cul, CSA / Canadian Standards Association.
Application: Internal wiring & external wiring of electronic appliances.
Outstanding Feature: suitable for use with sensors.

Parameters of UL20694 Automatic Device Sensor Connected Spiral Cable 80C 450V

Style Number Core Quantity Copper Conductor Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
UL20694 2C 30 7/0.100 0.23 0.80 0.76 3.20 381.00
2C 28 7/0.127 0.23 0.90 0.76 3.40 239.00
2C 26 7/0.16 0.23 1.00 0.76 3.60 150.00
2C 24 11/0.16 0.23 1.10 0.76 3.80 94.20
2C 22 17/0.16 0.23 1.30 0.76 4.20 59.40
2C 20 21/0.178 0.23 1.50 0.76 4.60 36.70
2C 18 34/0.178 0.23 1.80 0.76 5.20 23.20
2C 16 26/0.25 0.23 2.00 0.76 5.80 14.60
3C 30 7/0.100 0.23 0.80 0.76 3.40 381.00
3C 28 7/0.127 0.23 0.90 0.76 3.50 239.00
3C 26 7/0.16 0.23 1.00 0.76 3.80 150.00
3C 24 11/0.16 0.23 1.10 0.76 4.00 94.20
3C 22 17/0.16 0.23 1.30 0.76 4.40 59.40
3C 20 21/0.178 0.23 1.50 0.76 4.80 36.70
3C 18 34/0.178 0.23 1.80 0.76 5.50 23.20
4C 30 7/0.100 0.23 0.80 0.76 4.80 381.00
4C 28 7/0.127 0.23 0.90 0.76 5.10 239.00
4C 26 7/0.16 0.23 1.00 0.76 5.30 150.00
4C 24 11/0.16 0.23 1.10 0.76 5.50 94.20
4C 22 17/0.16 0.23 1.30 0.76 6.00 59.40
4C 20 21/0.178 0.23 1.50 0.76 6.50 36.70
5C 30 7/0.100 0.23 0.80 0.76 5.00 381.00
5C 28 7/0.127 0.23 0.90 0.76 5.30 239.00
5C 26 7/0.16 0.23 1.00 0.76 5.60 150.00
5C 24 11/0.16 0.23 1.10 0.76 5.80 94.20
5C 22 17/0.16 0.23 1.30 0.76 6.40 59.40
6C 30 7/0.100 0.23 0.80 0.76 5.30 381.00
6C 28 7/0.127 0.23 0.90 0.76 5.60 239.00
6C 26 7/0.16 0.23 1.00 0.76 5.90 150.00
6C 24 11/0.16 0.23 1.10 0.76 6.20 94.20
