UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
Specifications
Brand Name :
WCH Cable
Model Number :
UL20554
Certification :
UL, CUL, AWM
Place of Origin :
Dongguan, China
MOQ :
200 pcs
Price :
USD0.343 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000pcs per week
Delivery Time :
9 days for ready goods
Packaging Details :
200 pcs per box
Conductor :
High purity copper wire
Rated Temperature :
80 Deg C
Insulation :
AWM Appliant Material
Rated Voltage :
30V
Jacket Material :
Thermoplastic Polyurethane TPU
Standard Reference :
UL758, UL20554
Description

Feature of UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

Conductor: High purity copper wire, tinned or bare, stranded or solid.
Insulation: Quality materials complying with AWM standard.
Screen Shield: Foil, spiral shield, copper braiding, optional.
Jacket: Thermoplastic Polyurethane TPU.
Standard: Appliance Wiring Material UL758.
Rated Temperature: 80 deg C.
Rated Voltage: 30V.
Flammability: UL VW-1 passed.
Uniform insulation thickness for smooth stripping.
Other approvals: Cul, CSA / Canadian Standards Association.
Application: Internal wiring & external wiring of electronic appliances.
Outstanding Feature: wonderful quality of Polyurethane coated materials as jacket.

Parameters of UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

Style Number Core Quantity Copper Conductor Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
UL20554 2C 30 7/0.100 0.23 0.80 0.38 3.20 381.00
2C 28 7/0.127 0.23 0.90 0.38 3.40 239.00
2C 26 7/0.16 0.23 1.00 0.38 3.60 150.00
2C 24 11/0.16 0.23 1.10 0.38 3.80 94.20
2C 22 17/0.16 0.23 1.30 0.38 4.20 59.40
2C 20 21/0.178 0.23 1.50 0.38 4.60 36.70
2C 18 34/0.178 0.23 1.80 0.38 5.20 23.20
2C 16 26/0.25 0.23 2.00 0.38 5.80 14.60
3C 30 7/0.100 0.23 0.80 0.38 3.40 381.00
3C 28 7/0.127 0.23 0.90 0.38 3.50 239.00
3C 26 7/0.16 0.23 1.00 0.38 3.80 150.00
3C 24 11/0.16 0.23 1.10 0.38 4.00 94.20
3C 22 17/0.16 0.23 1.30 0.38 4.40 59.40
3C 20 21/0.178 0.23 1.50 0.38 4.80 36.70
3C 18 34/0.178 0.23 1.80 0.38 5.50 23.20
4C 30 7/0.100 0.23 0.80 0.38 4.80 381.00
4C 28 7/0.127 0.23 0.90 0.38 5.10 239.00
4C 26 7/0.16 0.23 1.00 0.38 5.30 150.00
4C 24 11/0.16 0.23 1.10 0.38 5.50 94.20
4C 22 17/0.16 0.23 1.30 0.38 6.00 59.40
4C 20 21/0.178 0.23 1.50 0.38 6.50 36.70
5C 30 7/0.100 0.23 0.80 0.38 5.00 381.00
5C 28 7/0.127 0.23 0.90 0.38 5.30 239.00
5C 26 7/0.16 0.23 1.00 0.38 5.60 150.00
5C 24 11/0.16 0.23 1.10 0.38 5.80 94.20
5C 22 17/0.16 0.23 1.30 0.38 6.40 59.40
6C 30 7/0.100 0.23 0.80 0.38 5.30 381.00
6C 28 7/0.127 0.23 0.90 0.38 5.60 239.00
6C 26 7/0.16 0.23 1.00 0.38 5.90 150.00
6C 24 11/0.16 0.23 1.10 0.38 6.20 94.20


UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

Spiral coiling process of UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V


UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V
UL20554 WCH Cable Produced Polyurethane Coated Spiral Coil Cable 80C 30V

Tag: spiral cable, coil cable, coiled cable, ul20554
