Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
Specifications
Brand Name :
WCH Cable
Model Number :
UL20842
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
100 pcs
Price :
USD 0.211 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000000 pcs per Month
Delivery Time :
9 days for ready goods
Packaging Details :
200 pcs per carton box
Feature :
Waterproof, Water Resistat
Application :
Handset
Conductor :
High Purity Copper
UL Style :
UL20842, UL20843, UL20844
Jacket :
Thermoplastic Elastomer
LSZH :
Halogen Free
Description

Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844

Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844

Spiral Cable
Construction		 Spiral Length (unexpanded) (mm) 80
Straight Ends (mm/mm) 610/350
Extension Ratio 　 1:3.8
Spiral Outer Ø (mm) 17.5
Tail Direction 　 180 degree
End Treatment Optional Cut Flat, Stripped/Tinned
Electrical
Capability		 Working Voltage (V) 300
Temperature Range (°C) 80
Test Voltage (V) 2000/3000
Nominal Voltage (V) 300
Conductor Resistance (Ω/KM at 20°C) 14.60
Insulation Resistance (MΩ/KM at 20°C) 100
Standard & Use UL Style Number Optional Per UL20842, UL20843, UL20843
CUL Standard 　 II A
Flammability 　 FT1, VW-1
Raw Cable
Construction		 Conductor Size (AWG) 16
Insulation Material 　 TPE (RoHS)
Insulation Diameter (mm) 2.20
Conductor Quantity 　 2 Cores
Assembly 　 Twisted
Overall Diameter (mm) 5.30
Jacket Material 　 TPE (RoHS)
Surface Effect 　 Matt Blue

The demonstrated parameters for reference only. Please consult our customer service to customize any other parameter you demand.

Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844

Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844Waterproof Handset Retractile Curly Cord UL20842, UL20843, UL20844
