Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
Specifications
Brand Name :
Hunter Men
Model Number :
HT07-40P
Certification :
SGS, ISO9001
Place of Origin :
Shenzhen,China
MOQ :
5000 ㎡
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T, D/A, D/P,Alibaba，Paypal
Supply Ability :
30000 ㎡ per day
Delivery Time :
3-15 work days (depends on the order quantity)
Packaging Details :
100meters/Roll and PE bag package,1 rolls in Carton (can be customized)
Main raw material :
Polyurethane
Feature :
Springback No Deformation
Melt Flow Index: :
35±5g/10min (Condition:190℃,2.16Kg)
Melt Point :
120℃
Work Temperature :
170-190℃
Width :
1500mm (can be customized)
Length :
100 Meters per Roll (can be customized)
Usage :
Traceless Briefs
Description

Springback No Deformation TPU Thermal Bonding Garment Accessories for Traceless Briefs
Model Number:HT07-40P
Description:
HT07-40P is thermoplastic material, suitable for a variety of materials, it can stick to materials after one or more times melt by hot temperature,after hot melting and quickly cold speed feature make it use to various high speed production.It performs an excellent adhesion for Fabrics,Diving Fabrics,Laica,Jersey, other elastic fabrics and so on. This adhesive product possesses excellent washability and with good dry cleaning and chemical additives resistant.
Features&Usages:
It has good resilience, elasticity, heat resistance, cold resistance and water resistance.This adhesive product possesses excellent chemical additives resistant, It main used to composite elastic fabrics to produce can be used as a health-care vest, an underwear, a health-care waistband, kneepads etc.
Operate machine:iron,high-frequency machine,heat roller machine,flat-bed heat press machine or other hot composite machine.
Physical Characteristics:

Color Transparent Release Liner Double Silicone Glassine Release paper
Density 1.2±0.02g/cm³ Conventional thickness 30mic,50mic,80mic,100mic (can be customized)
Melt Flow Index 35±5g/10min
 Conventional Width 1500mm (can be customized)
Hardness (Shore A) 60A Length 100meters(can be customized)
Flow Beginning Point 120℃ Normal Size /Rolls

1535mm(width)*100meters(Length) (can be customized)

Recommended Bonding Conditions:

First Backing Operate Second Hot Pressure Operate
Backing Temperature 130℃-150℃ Hot Pressure Temperature 150℃-190℃
Hot Pressing Speed 20m/min Hot Pressure Speed 15m/min
Pressure 0.5-1.5KG/CM² Pressure 0.5-1.5KG/CM²

Note: Due to the different bonding materials have different heat-shielding performance, the operation parameters in the technical data are only for reference. The specific hot pressing temperature, pressure and time shall be adjusted according to the different bonding materials, operating equipment and process.(Please don’t use steam when you operate by flatiron.)

Storage Conditions:
Stored in dry unopened packaging at room temperature at least 2 years.

Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs

Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs

Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs
How to use it:
Springback TPU Thermal Bonding Adhesive Film 1500mm No Deformation For Traceless Briefs

FAQ:

1 .How about hot melt adhesive film?
A: It is just a film, and the basic material is release paper. But the film is solid in room temperature, after heat pressure, it is able to bond other materials, Different materials hot melt adhesive film have different performances and different usages, we need know your demands clearly first ,then we can recommend good products for you.
2.Do you accept OEM or ODM?
Yes ,we accept OEM and ODM, we are professional heat transfer material manufacturer ,having over 10 years experience. we are able to assist you to R&D new products. So if you need bonding some special materials, please don't hesitate to let us know.
3.How do you transport the products?
If you are not urgent, we usually transport by ship because it is the cheapest way. But for the West Asia area,
we deliver by train because there is no sea to ship. And for samples and urgent cargo, we transport it by air as it is the fastest way .Of course if you have other better idea about transport, we will accept it.
4. May I have your samples?
If you need some samples for reference, please let us know your fully address/ship
mode with courier ,and we will arrange samples to you.
5. How long is the lead time?
Sample lead time:3-7 days
Bulk lead time:7-10 days(depends on order quantity)

6. How do I pay for my order?
We accept L/C ,T/T ,Western Union , Paypal.
